Samsung PM1735a Enterprise SSD - 7.68TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLJ7T6HALA-00B7C | Part #: MZWLJ7T6HALA-00B7C | MPN: MZWLJ7T6HALA-00B7C
Contact for Pricing — Request a Quote
About the Samsung PM1735a Enterprise SSD - 7.68TB
The Samsung PM1735a Enterprise SSD delivers enterprise-class NVMe performance in a Half-Height Half-Length (HHHL) Add-In Card form factor, designed for direct PCIe Gen 4.0 x8 backplane integration in high-density server environments. With sequential read speeds up to 8,000 MB/s and sequential write performance reaching 4,000 MB/s, this 7.68TB drive eliminates I/O bottlenecks in mission-critical workloads. The standout specification lies in random access performance: 1.5 million read IOPS and 200,000 write IOPS at queue depth 256 position this Samsung solution as a leader for latency-sensitive, transactional databases and real-time analytics clusters.
Storage architects and data center infrastructure teams select the PM1735a (part number MZWLJ7T6HALA-00B7C) for enterprise deployments where capacity and throughput must coexist without compromise. The Samsung V-NAND MLC technology delivers 1,400 TBW endurance with 2,000,000-hour MTBF, ensuring predictable lifecycle costs across three to five-year hardware refresh cycles. Enterprise-grade security—AES 256-bit encryption, TCG Opal 2.0, and IEEE 1667 compliance—satisfies regulated industries including financial services, healthcare, and government sectors. Capacitor-backed power loss protection and end-to-end T10 DIF/DIX data integrity verification provide the fault tolerance expected in Tier-1 infrastructure, while modest 25W active power consumption reduces cooling overhead in dense server configurations.
Samsung enterprise SSDs represent a proven investment for organizations standardizing on PCIe NVMe architecture. Omnixon Global supplies the PM1735a and complementary enterprise storage solutions to system integrators, data center operators, and Fortune 500 IT procurement teams across the UAE, GCC region, and beyond. For technical specifications, volume pricing, lead times, and integration support, contact Omnixon Global to submit your RFQ today.
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLJ7T6HALA-00B7C |
| Part Number | MZWLJ7T6HALA-00B7C |
| Condition | New |
| Capacity | 7.68TB |
| Form Factor | E1.S |
| Interface | PCIe Gen5 |
| Speed | Read: 8,000 MB/s, Write: 3,800 MB/s |
| Manufacturer Part Number | MZWLJ7T6HALA-00B7C |
| Capacity | 7.68 TB |
| Form Factor | HHHL (Half-Height Half-Length) Add-In Card (AIC) |
| Interface | PCIe Gen 4.0 x8 |
| Protocol | NVMe 1.3 |
| NAND Type | Samsung V-NAND (MLC) |
| Sequential Read | Up to 8,000 MB/s |
| Sequential Write | Up to 4,000 MB/s |
| Random Read (4K QD256) | Up to 1,500,000 IOPS |
| Random Write (4K QD256) | Up to 200,000 IOPS |
| Endurance (TBW) | 1,400 TBW |
| Drive Write Per Day (DWPD) | ~0.1 DWPD over rated life |
| Power Consumption (Active Read) | Up to 25 W |
| Power Consumption (Active Write) | Up to 25 W |
| Power Loss Protection | Yes (capacitor-based) |
| Encryption | AES 256-bit, TCG Opal 2.0, IEEE 1667 |
| Data Integrity | End-to-end T10 DIF/DIX |
| Operating Temperature | 0°C to 70°C |
| MTBF | 2,000,000 hours |
| Operating System Compatibility | Windows Server, Linux (kernel 4.x and later), VMware ESXi |
Frequently Asked Questions about Samsung PM1735a Enterprise SSD - 7.68TB
What does the Samsung PM1735a Enterprise SSD - 7.68TB do?
At 7.68TB, the Samsung PM1735a Enterprise SSD - 7.68TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The PCIe 5.0 x4 interface is supported by major server platforms.
What are the headline specs of the Samsung PM1735a Enterprise SSD - 7.68TB?
Key specifications for the Samsung PM1735a Enterprise SSD - 7.68TB: capacity 7.68TB; form factor E1.S; interface PCIe 5.0 x4; new condition; drive media type SSD; storage form factor HHHL AIC; storage capacity 7.68TB; storage interface PCIe 4.0 x4; drive media type SSD; storage form factor E1.S. Manufacturer part number MZWLJ7T6HALA-00B7C. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1735a Enterprise SSD - 7.68TB compatible with my infrastructure?
The Samsung PM1735a Enterprise SSD - 7.68TB uses a PCIe 5.0 x4 interface in a E1.S form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
