Samsung PM1653 Enterprise SSD - 3.84TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLL3T8HBLA-00B7C | Part #: MZWLL3T8HBLA-00B7C | MPN: MZWLL3T8HBLA-00B7C
Contact for Pricing — Request a Quote
About the Samsung PM1653 Enterprise SSD - 3.84TB
The Samsung PM1653 Enterprise SSD delivers read-intensive cache performance with up to 800,000 random read IOPS, making it ideal for high-frequency data access in virtualized environments, databases, and mixed-workload primary storage tiers. Part number MZWLL3T8HBLA-00B7C represents Samsung's commitment to enterprise-grade reliability, combining 3.84TB capacity with dual-port SAS 24Gb/s connectivity for redundancy and failover protection in mission-critical infrastructure.
Built on Samsung's 6th-generation V-NAND TLC architecture, this 2.5-inch form factor SSD delivers sequential read speeds up to 4,200 MB/s and sequential write speeds to 1,400 MB/s, enabling rapid data movement across storage clusters. The PM1653 includes enterprise security essentials: AES 256-bit encryption, TCG Enterprise compliance, and FIPS 140-2 certification alongside T10 PI end-to-end data protection. Storage architects and IT procurement teams favor this drive for its 1,401 TBW endurance rating, 0.2 DWPD 5-year guarantee, and extended 2,000,000-hour MTBF. Power efficiency remains strong at 11W active read and 5W idle consumption, reducing data center thermal load. Onboard capacitor-based power-loss protection safeguards in-flight data during unexpected power events. Operating across 0–70°C, the PM1653 integrates seamlessly into standardized 2.5-inch SFF storage arrays with minimal rack footprint. Contact Omnixon Global for detailed specifications, compatibility assessments, and customized quotations.
Key Specifications
- Capacity: 3.84 TB
- Interface: SAS 24Gb/s dual port
- Random Read (4K): Up to 800,000 IOPS
- Endurance: 1,401 TBW, 0.2 DWPD (5-year)
- Security: AES 256-bit, TCG Enterprise, FIPS 140-2
- MTBF: 2,000,000 hours
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLL3T8HBLA-00B7C |
| Part Number | MZWLL3T8HBLA-00B7C |
| Condition | New |
| Capacity | 3.84TB |
| Form Factor | 2.5" |
| Interface | SAS 12Gb/s |
| Speed | Read: 2,100 MB/s, Write: 1,200 MB/s |
| Manufacturer Part Number | MZWLL3T8HBLA-00B7C |
| Capacity | 3.84 TB |
| Form Factor | 2.5-inch (SFF), 15mm z-height |
| Interface | SAS 24Gb/s (dual port) |
| NAND Technology | Samsung 6th Generation V-NAND (TLC) |
| Sequential Read | Up to 4,200 MB/s |
| Sequential Write | Up to 1,400 MB/s |
| Random Read (4K) | Up to 800,000 IOPS |
| Random Write (4K) | Up to 180,000 IOPS |
| Endurance (TBW) | 1,401 TBW |
| Endurance Rating (DWPD) | 0.2 DWPD (5-year) |
| Power Consumption (Active Read) | 11 W |
| Power Consumption (Idle) | 5 W |
| Encryption | AES 256-bit, TCG Enterprise, FIPS 140-2 |
| Data Protection | T10 PI (Protection Information), end-to-end data path protection |
| Power-Loss Protection | Yes (onboard capacitor-based) |
| MTBF | 2,000,000 hours |
| Operating Temperature | 0°C to 70°C |
| Dimensions (W x H x D) | 69.85 mm x 15.0 mm x 100.45 mm |
| Weight | Approximately 138 g |
Frequently Asked Questions about Samsung PM1653 Enterprise SSD - 3.84TB
What does the Samsung PM1653 Enterprise SSD - 3.84TB do?
At 3.84TB, the Samsung PM1653 Enterprise SSD - 3.84TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SAS 12Gb/s interface is supported by major server platforms.
What are the headline specs of the Samsung PM1653 Enterprise SSD - 3.84TB?
Key specifications for the Samsung PM1653 Enterprise SSD - 3.84TB: capacity 3.84TB; form factor 2.5 inch (15mm); interface SAS 12Gb/s; new condition; drive media type SSD; storage form factor 2.5 inch (15mm); storage capacity 3.84TB; storage interface SAS 12Gb/s. Manufacturer part number MZWLL3T8HBLA-00B7C. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1653 Enterprise SSD - 3.84TB compatible with my infrastructure?
The Samsung PM1653 Enterprise SSD - 3.84TB uses a SAS 12Gb/s interface in a 2.5 inch (15mm) form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
