Samsung PM1653 Enterprise SSD - 1.92TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLL1T9HBLA-00B07 | Part #: MZWLL1T9HBLA-00B07 | MPN: MZWLL1T9HBLA-00B07
Contact for Pricing — Request a Quote
About the Samsung PM1653 Enterprise SSD - 1.92TB
The Samsung PM1653 Enterprise SSD is a 2.5-inch, 15mm-height form factor drive engineered for dual-port SAS 24Gb/s connectivity in high-density storage arrays. Delivering sequential read speeds up to 4,300 MB/s and write throughput of 3,800 MB/s at deep queue depths, this Samsung solution (MZWLL1T9HBLA-00B07) provides the sustained performance required for demanding enterprise workloads. With 1,000,000 random read IOPS and 180,000 write IOPS at 4K block size, the PM1653 ensures responsive I/O operations across virtualized environments and transactional databases.
Built on Samsung V-NAND TLC technology with 1 DWPD endurance rating over five years, this drive incorporates capacitor-based power loss protection, AES 256-bit SED encryption, and T10 DIF/DIX data integrity checking—critical features for storage architects and enterprise IT teams standardizing on mission-critical infrastructure. Operating across 0°C to 70°C with minimal idle power draw of 5.0W, the PM1653 balances performance with thermal efficiency. Enterprise storage architects, data center managers, and IT procurement teams rely on this drive's proven reliability and dual-port redundancy to eliminate single points of failure in SAN environments.
Typical Deployment Scenarios
- High-availability SAN arrays requiring redundant dual-port connectivity and fault tolerance
- Virtualized infrastructure with sustained random I/O across hundreds of concurrent virtual machines
- Transactional databases (Oracle, SQL Server) demanding consistent sub-millisecond latency
- RAID-protected storage pools in mid-market and enterprise data centers
- Mixed-workload environments combining OLTP and analytics on shared storage fabric
Contact Omnixon Global in Dubai to request a detailed quote and specification verification for the Samsung PM1653 1.92TB Enterprise SSD.
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLL1T9HBLA-00B07 |
| Part Number | MZWLL1T9HBLA-00B07 |
| Condition | New |
| Capacity | 1.92TB |
| Form Factor | 2.5" |
| Interface | SAS 12Gb/s |
| Speed | Read: 2,100 MB/s, Write: 1,200 MB/s |
| Manufacturer Part Number | MZWLL1T9HBLA-00B07 |
| Capacity | 1.92 TB |
| Form Factor | 2.5-inch (SFF) |
| Height | 15 mm |
| Interface | SAS 24Gb/s (dual port) |
| NAND Technology | Samsung V-NAND (TLC) |
| Sequential Read Throughput | Up to 4,300 MB/s |
| Sequential Write Throughput | Up to 3,800 MB/s |
| Random Read IOPS (4K) | Up to 1,000,000 IOPS |
| Random Write IOPS (4K) | Up to 180,000 IOPS |
| Endurance (DWPD) | 1 DWPD (5-year rated) |
| Power Loss Protection | Yes (capacitor-based) |
| Data Integrity | End-to-end (T10 DIF/DIX) |
| Encryption | AES 256-bit SED, TCG Enterprise SSC |
| Idle Power | 5.0 W (typical) |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 70°C |
| Shock (Operating) | 1,500 G / 0.5 ms |
| Vibration (Non-Operating) | 20~2000 Hz, 3.13 Grms |
| MTBF | 2,000,000 hours |
Frequently Asked Questions about Samsung PM1653 Enterprise SSD - 1.92TB
What does the Samsung PM1653 Enterprise SSD - 1.92TB do?
At 1.92TB, the Samsung PM1653 Enterprise SSD - 1.92TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SAS 12Gb/s interface is supported by major server platforms.
What are the headline specs of the Samsung PM1653 Enterprise SSD - 1.92TB?
Key specifications for the Samsung PM1653 Enterprise SSD - 1.92TB: capacity 1.92TB; form factor 2.5 inch (15mm); interface SAS 12Gb/s; new condition; drive media type SSD; storage form factor 2.5 inch (15mm); storage capacity 1.92TB; storage interface SAS 12Gb/s. Manufacturer part number MZWLL1T9HBLA-00B07. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1653 Enterprise SSD - 1.92TB compatible with my infrastructure?
The Samsung PM1653 Enterprise SSD - 1.92TB uses a SAS 12Gb/s interface in a 2.5 inch (15mm) form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
