Samsung PM1653 Enterprise SSD - 7.68TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLL7T6HBLA-00B7C | Part #: MZWLL7T6HBLA-00B7C | MPN: MZWLL7T6HBLA-00B7C
Contact for Pricing — Request a Quote
About the Samsung PM1653 Enterprise SSD - 7.68TB
The Samsung PM1653 enterprise SSD (part number MZWLL7T6HBLA-00B7C) delivers 8,760 TBW endurance over five years at 1 DWPD, making it a purpose-built solution for write-intensive datacenter workloads. This 7.68TB 2.5-inch SFF drive pairs Samsung's proven 6th-generation V-NAND TLC technology with dual-port SAS 24Gb/s connectivity, achieving sequential read speeds up to 4,300 MB/s and 800,000 random read IOPS. With T10 DIF end-to-end data integrity protection, capacitor-backed power-loss safeguards, and AES 256-bit TCG Enterprise SSC encryption, the PM1653 addresses mission-critical reliability demands that standard commercial SSDs cannot match. The 2,000,000-hour MTBF rating reflects Samsung's enterprise-grade manufacturing standards.
Storage architects and IT procurement teams select the PM1653 when consolidating high-throughput applications—transactional databases, virtualized environments, and log-intensive workloads—into compact, power-efficient form factors. Its moderate 1 DWPD rating and 5-year endurance window suit predictable, steady-state I/O patterns rather than extreme burst scenarios. The drive's 10W active read and 5W idle power consumption minimize thermal footprint in dual-controller HA configurations, while its SAS dual-port design enables active-active failover without vendor lock-in. Samsung's established supply chain and firmware maturity in enterprise segments reduce integration risk and support costs.
Omnixon Global stocks the Samsung PM1653 7.68TB SAS enterprise SSD for immediate shipment across the UAE and GCC region. Our technical team can validate compatibility with your existing SAN infrastructure, coordinate volume licensing for fleet deployments, and expedite procurement cycles. Request a formal quote for the PM1653 (MZWLL7T6HBLA-00B7C) and speak with our enterprise storage specialists at Omnixon Global today.
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLL7T6HBLA-00B7C |
| Part Number | MZWLL7T6HBLA-00B7C |
| Condition | New |
| Capacity | 7.68TB |
| Form Factor | 2.5" |
| Interface | SAS 12Gb/s |
| Speed | Read: 2,100 MB/s, Write: 1,200 MB/s |
| Manufacturer Part Number | MZWLL7T6HBLA-00B7C |
| Series | PM1653 |
| Capacity | 7.68 TB |
| Form Factor | 2.5-inch (SFF) |
| Height | 15 mm |
| Interface | SAS 24Gb/s (dual port) |
| NAND Technology | Samsung 6th Generation V-NAND (TLC) |
| Sequential Read | Up to 4,300 MB/s |
| Sequential Write | Up to 1,500 MB/s |
| Random Read (4K) | Up to 800,000 IOPS |
| Random Write (4K) | Up to 140,000 IOPS |
| Drive Writes Per Day (DWPD) | 1 |
| Endurance (TBW) | ~8,760 TBW (over 5 years at 1 DWPD) |
| Power Consumption (Active Read) | Approximately 10 W |
| Power Consumption (Idle) | Approximately 5 W |
| MTBF | 2,000,000 hours |
| Data Integrity | T10 DIF (Data Integrity Field) end-to-end protection |
| Power-Loss Protection | Yes (capacitor-based) |
| Encryption | AES 256-bit self-encrypting drive (SED); TCG Enterprise SSC |
| Operating Temperature | 0°C to 70°C |
| Dimensions (W x H x D) | 69.85 mm x 15 mm x 100.45 mm |
Frequently Asked Questions about Samsung PM1653 Enterprise SSD - 7.68TB
What does the Samsung PM1653 Enterprise SSD - 7.68TB do?
At 7.68TB, the Samsung PM1653 Enterprise SSD - 7.68TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SAS 12Gb/s interface is supported by major server platforms.
What are the headline specs of the Samsung PM1653 Enterprise SSD - 7.68TB?
Key specifications for the Samsung PM1653 Enterprise SSD - 7.68TB: capacity 7.68TB; form factor 2.5 inch (15mm); interface SAS 12Gb/s; new condition; drive media type SSD; storage form factor 2.5 inch (15mm); storage capacity 7.68TB; storage interface SAS 12Gb/s. Manufacturer part number MZWLL7T6HBLA-00B7C. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1653 Enterprise SSD - 7.68TB compatible with my infrastructure?
The Samsung PM1653 Enterprise SSD - 7.68TB uses a SAS 12Gb/s interface in a 2.5 inch (15mm) form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
