Samsung PM1735a Enterprise SSD - 3.84TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLJ3T8HALA-00B7C | Part #: MZWLJ3T8HALA-00B7C | MPN: MZWLJ3T8HALA-00B7C
Contact for Pricing — Request a Quote
About the Samsung PM1735a Enterprise SSD - 3.84TB
The Samsung PM1735a Enterprise SSD (MZWLJ3T8HALA-00B7C) delivers exceptional power efficiency at just 3.65W per TB during active operations, making it ideal for hyperscale data centers and dense all-flash arrays where TCO and thermal management drive procurement decisions. With 25W peak active power consumption and 14W idle draw, this 3.84TB HHHL AIC form factor drive minimizes cooling overhead in high-density storage architectures while maintaining enterprise-grade reliability and performance.
Purpose-built for mission-critical workloads, the Samsung PM1735a combines PCIe Gen 4.0 x8 NVMe 1.4 connectivity with V-NAND MLC technology to deliver 8,000 MB/s sequential read speeds and 1.5M random read IOPS at QD256. Storage architects and IT procurement teams standardizing on Samsung enterprise solutions benefit from proven multi-stream write capabilities, AES 256-bit encryption, capacitor-based power loss protection, and end-to-end data integrity features. The MZWLJ3T8HALA-00B7C operates reliably across 0–70°C environments, supporting namespace management for flexible virtualization and workload isolation in containerized and Kubernetes deployments.
Key Specifications
- Capacity: 3.84 TB
- Interface: PCIe Gen 4.0 x8, NVMe 1.4
- Form Factor: HHHL AIC (Half-Height Half-Length Add-In Card)
- Sequential Read Performance: Up to 8,000 MB/s
- Random Read IOPS (4K QD256): Up to 1,500,000 IOPS
- Power Consumption (Active): 25W; (Idle) 14W
- Security: AES 256-bit encryption with power loss protection
For enterprise storage deployments requiring proven Samsung reliability and performance density, contact Omnixon Global to request an RFQ for the PM1735a MZWLJ3T8HALA-00B7C and explore volume pricing options tailored to your infrastructure requirements.
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLJ3T8HALA-00B7C |
| Part Number | MZWLJ3T8HALA-00B7C |
| Condition | New |
| Capacity | 3.84TB |
| Form Factor | HHHL AIC |
| Interface | PCIe Gen4 |
| Speed | Read: 8,000 MB/s, Write: 3,800 MB/s |
| Manufacturer Part Number | MZWLJ3T8HALA-00B7C |
| Product Line | PM1735a |
| Capacity | 3.84 TB |
| Form Factor | HHHL AIC (Half-Height Half-Length Add-In Card) |
| Interface | PCIe Gen 4.0 x8, NVMe 1.4 |
| NAND Technology | Samsung V-NAND (MLC) |
| Sequential Read | Up to 8,000 MB/s |
| Sequential Write | Up to 3,800 MB/s |
| Random Read (4K QD256) | Up to 1,500,000 IOPS |
| Random Write (4K QD256) | Up to 250,000 IOPS |
| Power Consumption (Active Read) | Up to 25 W |
| Power Consumption (Idle) | Up to 14 W |
| Power Loss Protection | Yes (capacitor-based) |
| End-to-End Data Protection | Yes |
| Encryption | AES 256-bit |
| Namespace Support | Yes (NVMe Namespace Management) |
| Multi-Stream Write | Yes |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -45°C to 85°C |
| MTBF | 2,000,000 hours |
Frequently Asked Questions about Samsung PM1735a Enterprise SSD - 3.84TB
What does the Samsung PM1735a Enterprise SSD - 3.84TB do?
At 3.84TB, the Samsung PM1735a Enterprise SSD - 3.84TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The PCIe 4.0 x4 interface is supported by major server platforms.
What are the headline specs of the Samsung PM1735a Enterprise SSD - 3.84TB?
Key specifications for the Samsung PM1735a Enterprise SSD - 3.84TB: capacity 3.84TB; form factor HHHL AIC; interface PCIe 4.0 x4; new condition; drive media type SSD; storage form factor HHHL AIC; storage capacity 3.84TB; storage interface PCIe 4.0 x4. Manufacturer part number MZWLJ3T8HALA-00B7C. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1735a Enterprise SSD - 3.84TB compatible with my infrastructure?
The Samsung PM1735a Enterprise SSD - 3.84TB uses a PCIe 4.0 x4 interface in a HHHL AIC form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
