Kingston Server Premier 64GB DDR5 6400MT/s ECC Registered DIMM 2Rx4 (KSM64R52BD4-64HA)

Kingston Server Premier 64GB DDR5 6400MT/s ECC Registered DIMM 2Rx4 (KSM64R52BD4-64HA)

64GB of DDR5 6400MT/s ECC Registered memory for high-capacity server platforms.

The Kingston KSM64R52BD4-64HA is a 64GB DDR5 6400MT/s ECC Registered DIMM from the Server Premier line. It is a PC5-6400 CL52 Registered EC8 288-pin module with 2Rx4 ranking, built from forty 4G x 4-bit FBGA components using 16Gbit Hynix A-die DRAM. JEDEC timing is 52-52-52 at 1.1V.

Perfect for

• Virtualisation hosts adding memory capacity to run more virtual machines per server.
• Database servers expanding RAM for in-memory workloads and large datasets.
• Enterprise application servers providing ECC Registered memory for business-critical services.
• Server memory upgrades populating DDR5 RDIMM slots in platforms that support 6400MT/s modules.

Why buyers choose this model

• 64GB per module. Each DIMM provides 64GB capacity in an 8G x 80-bit organisation.
• DDR5 6400MT/s. The module runs at DDR5-6400 with JEDEC timing of 52-52-52 at 1.1V.
• ECC Registered design. It is a PC5-6400 CL52 Registered EC8 288-pin DIMM for server use.
• Dual-rank x4 build. The 2Rx4 module uses forty 4G x 4-bit FBGA components with 16Gbit Hynix A-die DRAM.
• 1.1V operation. VDD and VDDQ are 1.1V typical, with VPP at 1.8V typical.

Key specifications

Specifications as published by Kingston for this part number. The full list is in the Specifications tab.
