Kioxia CM7-R 7.680TB E3.S Dual x2 SSD
Brand: Kioxia | Category: Enterprise SSDs
SKU: KCM7XRJE7T68 | Part #: KCM7XRJE7T68 | MPN: KCM7XRJE7T68
Contact for Pricing — Request a Quote
About the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD
Achieve up to 7,000 MB/s sequential read performance with the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD, a next-generation enterprise storage solution built for hyperscale and mission-critical infrastructure. The E3.S 2T form factor combined with PCIe 5.0 x2 dual-port connectivity delivers unprecedented bandwidth and dual-host access capabilities for demanding data center environments.
Built on Kioxia's 3D TLC NAND technology, the KCM7XRJE7T68 drives random performance with 1,500,000 IOPS 4K read and 200,000 IOPS 4K write operations, while maintaining a 1 DWPD endurance rating for sustained enterprise workloads. The drive supports NVMe 2.0 protocol with namespace sharing and simultaneous dual-host access, enabling flexible deployment in clustered and redundant architectures. Security is built-in through TCG Opal 2.0 and AES-256 self-encrypting drive (SED) functionality. Operating across 0°C to 70°C with typical active power consumption of 14 W, this Kioxia solution is engineered for storage architects and AI infrastructure teams seeking maximum capacity and throughput density.
Ideal Enterprise Deployment Scenarios
- High-performance computing clusters requiring shared NVMe storage with dual-port simultaneous host access
- AI training and inference platforms demanding 7,000 MB/s sequential read rates and 1,500,000 IOPS random read performance
- Database acceleration and in-memory analytics workloads with 7.680TB capacity per drive
- Hyperscale data center storage nodes requiring E3.S form factor for compact, dense deployment
- Secure enterprise environments leveraging TCG Opal 2.0 and AES-256 encryption for compliance-driven applications
Contact Omnixon Global to request a quote for the Kioxia CM7-R (part number KCM7XRJE7T68) and explore volume pricing options for your enterprise storage initiative.
Technical Specifications
| Brand | Kioxia |
| Category | Enterprise SSDs |
| SKU | KCM7XRJE7T68 |
| Part Number | KCM7XRJE7T68 |
| Condition | New |
| Capacity | 7.680TB |
| Form Factor | E3.S |
| Interface | Dual x2 |
| Speed | Read:14000 Mb/s,Write:6750 Mb/s |
| Manufacturer Part Number | KCM7XRJE7T68 |
| Series | CM7-R |
| Form Factor | E3.S 2T (EDSFF) |
| Interface | PCIe 5.0 x2 (Dual Port) |
| Protocol | NVMe 2.0 |
| Raw Capacity | 7.680 TB |
| NAND Flash Type | Kioxia 3D TLC NAND |
| Sequential Read (Max) | 7,000 MB/s |
| Sequential Write (Max) | 2,700 MB/s |
| Random Read IOPS (4K) | 1,500,000 IOPS |
| Random Write IOPS (4K) | 200,000 IOPS |
| Endurance (Drive Writes Per Day) | 1 DWPD |
| Power Consumption (Active) | 14 W (typical) |
| Operating Temperature | 0°C to 70°C |
| Dual-Port Support | Yes — simultaneous dual-host access |
| Namespace Sharing | Supported |
| Security | TCG Opal 2.0, AES-256 self-encrypting drive (SED) |
Frequently Asked Questions about Kioxia CM7-R 7.680TB E3.S Dual x2 SSD
What does the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD do?
At 7.680TB, the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The Dual x2 interface is supported by major server platforms.
What are the headline specs of the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD?
Key specifications for the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD: capacity 7.680TB; form factor E3.S; interface Dual x2; Manufacturer support support; new condition; model CM7-R; capacity 7.680TB; interface Dual x2; form factor E3.S; sequential read speed 14000 Mb/s; sequential write speed 6750 Mb/s. Manufacturer part number KCM7XRJE7T68. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Kioxia CM7-R 7.680TB E3.S Dual x2 SSD compatible with my infrastructure?
The Kioxia CM7-R 7.680TB E3.S Dual x2 SSD uses a Dual x2 interface in a E3.S form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
