Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD
Brand: Solidigm | Category: Enterprise SSDs
SKU: SOL-SSDPF2NV153TZN1 | Part #: SSDPF2NV153TZN1 | MPN: SSDPF2NV153TZN1
Contact for Pricing — Request a Quote
About the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD
The Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD from Solidigm is enterprise-grade Enterprise SSDs hardware built for data centers. It features 15.36TB capacity, PCIe form factor, NVMe interface. The Solidigm D5-P5336 series, represented by part number SSDPF2NV153TZN1, delivers 15.36TB of QLC NAND flash capacity in a U.2 2.5-inch form factor, connected via a PCIe Gen 4 x4 NVMe 1.4 interface. Built on Solidigm's fourth-generation QLC 3D NAND technology, this drive is engineered to close the performance gap between QLC and TLC media, making it well-suited for read-intensive and mixed-workload environments at data center scale. The architecture prioritizes high sequentia Available in brand new condition. Solidigm enterprise ssds products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Solidigm |
| Category | Enterprise SSDs |
| SKU | SOL-SSDPF2NV153TZN1 |
| Part Number | SSDPF2NV153TZN1 |
| Condition | New |
| Capacity | 15.36TB |
| Form Factor | PCIe |
| Interface | NVMe |
| Series | D5-P5336 |
| Manufacturer Part Number | SSDPF2NV153TZN1 |
| Capacity | 15.36 TB |
| Form Factor | U.2 2.5-inch (15mm) |
| Interface | PCIe Gen 4 x4 |
| Protocol | NVMe 1.4 |
| NAND Flash Type | QLC (Quad-Level Cell) 3D NAND |
| Sequential Read Throughput | Up to 7,000 MB/s |
| Sequential Write Throughput | Up to 3,000 MB/s |
| Random Read IOPS (4K) | Up to 1,500,000 IOPS |
| Random Write IOPS (4K) | Up to 150,000 IOPS |
| Power Loss Protection | Yes (capacitor-based) |
| Hardware Encryption | AES 256-bit |
| Security | TCG Opal 2.01, TCG Enterprise |
| End-to-End Data Protection | Yes |
| Endurance (TBW) | 2,800 TBW |
| Drive Writes Per Day (DWPD) | 0.1 |
| Active Power (Typical) | 25 W |
| Operating Temperature | 0°C to 70°C |
| MTBF | 2,000,000 hours |
Frequently Asked Questions about Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD
What does the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD do?
At 15.36TB, the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The NVMe interface is supported by major server platforms.
What are the headline specs of the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD?
Key specifications for the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD: capacity 15.36TB; form factor PCIe NVMe; interface NVMe; new condition; capacity 15.36TB; series D5 / D7 Series; interface / form factor PCIe NVMe; drive class Enterprise SSD; use case Servers, storage arrays, virtualization, and cloud infrastructure. Manufacturer part number SSDPF2NV153TZN1. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD compatible with my infrastructure?
The Solidigm / Intel SSDPF2NV153TZN1 D5 / D7 Series 15.36TB PCIe NVMe SSD uses a NVMe interface in a PCIe NVMe form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
