WD Ultrastar DC HC690 24TB Enterprise HDD
Brand: Western Digital | Category: Enterprise HDDs
SKU: 0F63135 | Part #: 0F63135 | MPN: WUH722424AL
Contact for Pricing — Request a Quote
About the WD Ultrastar DC HC690 24TB Enterprise HDD
SATA 6Gb/s, 3.5-inch form factor enterprise HDD with 2,500,000-hour MTBF — the WD Ultrastar DC HC690 24TB (part number WUH722424AL) delivers massive capacity and proven reliability for mission-critical data centres. Manufactured by Western Digital, this drive combines 24 TB of formatted capacity with Shingled Magnetic Recording (SMR) technology, enabling cost-effective storage expansion at scale. The hermetically sealed HelioSeal enclosure filled with helium maintains optimal performance across the full operating temperature range of 0°C to 60°C, while the 512 MB cache buffer optimizes throughput for sequential workloads. With an annualized failure rate of just 0.35% and a non-recoverable read error rate of 1 per 10^15 bits read, this drive is engineered for long-term deployment in demanding environments.
Built for storage architects and IT procurement teams managing large-scale capacity requirements, the DC HC690 operates at 7,200 RPM and consumes approximately 9.0 W during active read/write operations. Its 180 TB/year workload rate rating supports consistent performance in multi-drive arrays, while RoHS compliance ensures environmental responsibility. Measuring 101.85 mm × 147 mm × 26.1 mm and weighing approximately 650 g, the drive integrates seamlessly into standard 3.5-inch rack enclosures. Western Digital's proven enterprise-grade design makes this model an ideal choice for organizations seeking reliable, high-capacity storage without premium price tags.
Typical Enterprise Deployment Scenarios
- Archive and cold-storage tiers in hybrid cloud infrastructure requiring capacity at minimal operating cost
- Large-scale backup repositories where MTBF and annual failure rates directly impact TCO
- Data warehouse expansion for organizations growing beyond 100 TB per site
- Multi-drive NAS and SAN arrays prioritizing reliability over extreme performance
- Long-term retention systems subject to RoHS and environmental compliance mandates
For pricing, availability, and lead times on the WD Ultrastar DC HC690 24TB (WUH722424AL), contact Omnixon Global to submit your RFQ today.
Technical Specifications
| Brand | Western Digital |
| Category | Enterprise HDDs |
| SKU | 0F63135 |
| Part Number | 0F63135 |
| MPN | WUH722424AL |
| Condition | New |
| Capacity | 24TB |
| Form Factor | 3.5" |
| Interface | SATA 6Gb/s |
| Speed | 7,200 RPM |
| Model | DC HC690 |
| Manufacturer Part Number | 0F63135 |
| Formatted Capacity | 24 TB |
| Recording Technology | Shingled Magnetic Recording (SMR) |
| Interface | SATA 6Gb/s |
| Rotational Speed | 7,200 RPM |
| Form Factor | 3.5-inch |
| Cache (Buffer) | 512 MB |
| Mean Time Between Failures (MTBF) | 2,500,000 hours |
| Annualized Failure Rate (AFR) | 0.35% |
| Operating Temperature | 0°C to 60°C |
| Power Consumption (Active, Read/Write) | Approximately 9.0 W |
| Enclosure Technology | HelioSeal (hermetically sealed, helium-filled) |
| Workload Rate Rating | 180 TB/year |
| Non-recoverable Read Errors | 1 per 10^15 bits read |
| Dimensions | 101.85 mm (W) × 147 mm (D) × 26.1 mm (H) |
| Weight | Approximately 650 g |
| RoHS Compliant | Yes |
Frequently Asked Questions about WD Ultrastar DC HC690 24TB Enterprise HDD
What does the WD Ultrastar DC HC690 24TB Enterprise HDD do?
At 24TB, the WD Ultrastar DC HC690 24TB Enterprise HDD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SATA 6Gb/s interface is supported by major server platforms.
What are the headline specs of the WD Ultrastar DC HC690 24TB Enterprise HDD?
Key specifications for the WD Ultrastar DC HC690 24TB Enterprise HDD: capacity 24TB; form factor 3.5"; interface SATA 6Gb/s; new condition; product name WD Ultrastar DC HC690 24TB Enterprise HDD; brand Western Digital; category Hard Drive (HDD); capacity 24TB; form factor 3.5 inches; interface SATA 6Gb/s. Manufacturer part number 0F63135. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the WD Ultrastar DC HC690 24TB Enterprise HDD compatible with my infrastructure?
The WD Ultrastar DC HC690 24TB Enterprise HDD uses a SATA 6Gb/s interface in a 3.5" form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
