WD Ultrastar DC HC580 24TB Enterprise HDD
Brand: Western Digital | Category: Enterprise HDDs
SKU: 0F63210 | Part #: 0F63210 | MPN: WUH722424BL
Contact for Pricing — Request a Quote
About the WD Ultrastar DC HC580 24TB Enterprise HDD
Built for 24×7 nearline, sustained sequential, and cold archive workloads, the WD Ultrastar DC HC580 24TB Enterprise HDD delivers a proven Mean Time Between Failures (MTBF) of 2,500,000 hours and an annualized failure rate of 0.35%, making it a cornerstone choice for mission-critical data centers. This Western Digital drive combines 24TB of formatted capacity in a compact 3.5-inch form factor (26.1mm height) with SATA 6Gb/s connectivity and a 512MB cache buffer. The DC HC580 employs CMR recording technology enhanced with EAMR (Energy-Assisted) and OptiNAND, spinning at 7200 RPM to balance performance and efficiency. With 512-byte sector emulation and a rotational vibration sensor included, this model (part number WUH722424BL, manufacturer part number 0F63210) handles non-recoverable read errors at a rate of just 1 per 10^15 bits read—a hallmark of enterprise-grade reliability.
Storage architects, IT procurement teams, and data center operators choose the Western Digital Ultrastar DC HC580 for large-scale nearline repositories and archive deployments where sustained throughput and uptime matter most. The 550TB annual workload rating supports demanding multi-user environments without sacrificing durability, while the helium platform reduces active power consumption compared to conventional air-filled alternatives. Operating safely across 0°C to 60°C, with non-operating temperature tolerance from –40°C to 70°C, this drive integrates seamlessly into diverse thermal environments—from hyperscale facilities to distributed edge locations requiring robust cold-storage performance.
For organizations evaluating bulk enterprise storage solutions, Omnixon Global supplies the WD Ultrastar DC HC580 24TB (WUH722424BL) with full technical documentation and configuration guidance. Contact our team today to discuss your requirements and submit a request for quotation.
Technical Specifications
| Brand | Western Digital |
| Category | Enterprise HDDs |
| SKU | 0F63210 |
| Part Number | 0F63210 |
| MPN | WUH722424BL |
| Condition | New |
| Capacity | 24TB |
| Form Factor | 3.5" |
| Interface | SATA 6Gb/s |
| Speed | 7,200 RPM |
| Manufacturer Part Number | 0F63210 |
| Model | DC HC580 |
| Formatted Capacity | 24TB |
| Interface | SATA 6Gb/s |
| Recording Technology | CMR (Conventional Magnetic Recording) with EAMR (Energy-Assisted) and OptiNAND |
| Spindle Speed | 7200 RPM |
| Cache Buffer | 512MB |
| Form Factor | 3.5-inch |
| Drive Height | 26.1mm |
| Sectors per Drive | 512 bytes emulation (512e) |
| Rotational Vibration Sensor | Yes |
| Operating Temperature | 0°C to 60°C |
| Non-Operating Temperature | -40°C to 70°C |
| Power Mode - Active (Typical) | Available in product datasheet; helium platform reduces active power vs. air-filled equivalents |
| Mean Time Between Failures (MTBF) | 2,500,000 hours |
| Annualized Failure Rate (AFR) | 0.35% |
| Non-Recoverable Read Errors | 1 per 10^15 bits read |
| Workload Rate Limit | 550TB per year |
| RoHS Compliant | Yes |
| Encryption | Available in self-encrypting drive (SED) variants with TCG Enterprise and FIPS 140-2 options |
Frequently Asked Questions about WD Ultrastar DC HC580 24TB Enterprise HDD
What does the WD Ultrastar DC HC580 24TB Enterprise HDD do?
At 24TB, the WD Ultrastar DC HC580 24TB Enterprise HDD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SATA 6Gb/s interface is supported by major server platforms.
What are the headline specs of the WD Ultrastar DC HC580 24TB Enterprise HDD?
Key specifications for the WD Ultrastar DC HC580 24TB Enterprise HDD: capacity 24TB; form factor 3.5"; interface SATA 6Gb/s; new condition; product name WD Ultrastar DC HC580 24TB Enterprise HDD; brand Western Digital; category Hard Drive (HDD); capacity 24TB; form factor 3.5"; interface SATA 6Gb/s. Manufacturer part number 0F63210. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the WD Ultrastar DC HC580 24TB Enterprise HDD compatible with my infrastructure?
The WD Ultrastar DC HC580 24TB Enterprise HDD uses a SATA 6Gb/s interface in a 3.5" form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
