Brand: TP-Link | Category: Network Switches
SKU: TL-SG105-M2 | Part #: TL-SG105-M2 | MPN: TL-SG105-M2
Contact for Pricing — Request a Quote
Upgrade to a Super-Fast, Futuristic Network
5/8-Port 2.5G Desktop Switch
TL-SG105-M2/ TL-SG108-M2
Unlock the Highest Performance of
2.5G Multi-Gig Bandwidth and Devices
As the flagship 2.5G products, the 5/8-Port desktop switches with 5/8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices, and provide up to 25/40 Gbps of switching capacity. Auto-negotiation 3-speed (100Mb/1G/2.5G) connections sense the link speeds and intelligently adjust for compatibility and optimal performance for all your devices, including 2.5G NAS, 2.5G PCIe adapter, gaming console, VR gaming, 2.5G WiFi 6 AP, 4K video, desktop, and more.
Powerful Performance for Smooth LAN Parties
Never host a laggy LAN party again. Experience the unparalleled speed and lower latency, and prioritize gaming traffic with QoS. Let’s begin the unprecedented smooth game!
Ideal for Small and Home Office
Work at office or home with lightning-fast connections to workstations, desktop computers, and WiFi 6 access points.
2.5G Super-Fast Speeds
without Changing Cables
Flawlessly integrated into existing gigabit Ethernet network infrastructures, 2.5× faster speeds* with regular Cat5e Ethernet cables, without the need to upgrade to Cat6 wiring, reducing wiring costs and hassle.
Silent Operation with
Industry-Leading Fanless Design
The revolutionary fanless design ensures unprecedented silent operation, ideal for any home or business. Durable metal casing, desktop/wall-mounting design and professional heat dissipation design are well-suited for different environments.
Just Plug and Play for Internet Access
A plug-and-play design allows for easy deployment without the need for a technician. Auto MDI/MDIX eliminates the need for crossover cables.
| Brand | TP-Link |
| Category | Network Switches |
| SKU | TL-SG105-M2 |
| Part Number | TL-SG105-M2 |
| Condition | New |
| 2.5G Ethernet (copper) ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto-negotiation | Yes |
| 10G support | No |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Packet buffer memory | 1.5 MB |
| Jumbo frames | 10000 |
| Jumbo frames support | Yes |
| Store-and-forward | Yes |
| MAC address table | 16000 entries |
| Forwarding rate | 18.6 Mpps |
| Switching capacity | 25 Gbit/s |
| Power over Ethernet (PoE) | No |
| Switch type | Unmanaged |
| Power consumption (max) | 12.11 W |
| Input voltage | 12 V |
| Input current | 1 A |
| Power supply included | Yes |
| Power source | DC |
| LED indicators | Yes |
| Product colour | Black |
| Rack mounting | No |
| Heat dissipation | 41.32 BTU/h |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Height | 26 mm |
| Depth | 126 mm |
| Width | 209 mm |
| Certification | CE, FCC ,RoHS |
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
The TP-Link 5-PORT Unmanaged 2.5G Desktop Switch, Metal Case is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Arista environments.
Key specifications for the TP-Link 5-PORT Unmanaged 2.5G Desktop Switch, Metal Case: new condition; 2.5g ethernet (copper) ports quantity 5; basic switching rj-45 ethernet ports type 2.5G Ethernet (100/1000/2500); basic switching rj-45 ethernet ports quantity 5; auto mdi/mdi-x Yes; ethernet lan data rates 10,100,1000 Mbit/s; auto-negotiation Yes. Manufacturer part number TL-SG105-M2. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
The TP-Link 5-PORT Unmanaged 2.5G Desktop Switch, Metal Case interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
