Samsung PM1743 Enterprise SSD (Expected) - 7.68TB
Brand: Samsung | Category: Enterprise SSDs
SKU: MZWLJ7T6HALA-00B7C-V1 | Part #: MZWLJ7T6HALA-00B7C-V1 | MPN: MZWLJ7T6HALA-00B7C-V1
Contact for Pricing — Request a Quote
About the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB
The Samsung PM1743 Enterprise SSD delivers exceptional performance across read-intensive cache (2.5M read IOPS), write-intensive log (250K write IOPS), and mixed-workload primary storage tiers. This 7.68TB NVMe drive, part number MZWLJ7T6HALA-00B7C-V1, combines PCIe 5.0 x4 bandwidth with Samsung's proven 6th-generation V-NAND architecture to accelerate latency-sensitive applications in hyperscale data centers, AI inference clusters, and high-frequency transaction systems.
Enterprise storage architects and IT procurement teams selecting the PM1743 gain deterministic sub-millisecond latency, 13,000 MB/s sequential throughput, and hardware-enforced AES 256-bit encryption with TCG Opal 2.0 compliance. The E1.S form factor (9.5mm EDSFF) maximizes rack density while the 1 DWPD endurance rating and capacitor-backed power-loss protection ensure five-year operational stability in mission-critical environments. With end-to-end data protection (T10 DIF/DIX), multi-namespace support, and a 2,000,000-hour MTBF, Samsung positions this drive as a premium alternative to PCIe 4.0 incumbents. Active power draw remains efficient at approximately 14W, reducing total-cost-of-ownership in dense deployments. This unit is currently expected; contact Omnixon Global to submit your RFQ.
Key Specifications
- Capacity: 7.68 TB
- Interface: PCIe 5.0 x4, NVMe 2.0
- Form Factor: E1.S (9.5mm, EDSFF)
- Sequential Performance: Up to 13,000 MB/s read, 6,600 MB/s write
- Random Performance: Up to 2,500,000 IOPS read (4K), 250,000 IOPS write (4K)
- Security: AES 256-bit, TCG Opal 2.0, SED with T10 DIF/DIX protection
Technical Specifications
| Brand | Samsung |
| Category | Enterprise SSDs |
| SKU | MZWLJ7T6HALA-00B7C-V1 |
| Part Number | MZWLJ7T6HALA-00B7C-V1 |
| Condition | New |
| Capacity | 7.68TB |
| Form Factor | E1.S |
| Interface | PCIe Gen5 |
| Speed | Read: 13,000 MB/s, Write: 12,000 MB/s |
| Manufacturer Part Number | MZWLJ7T6HALA-00B7C-V1 |
| Series | PM1743 |
| Capacity | 7.68 TB |
| Form Factor | E1.S (9.5mm, EDSFF) |
| Interface | PCIe 5.0 x4, NVMe 2.0 |
| NAND Technology | Samsung 6th Generation V-NAND (TLC) |
| Sequential Read | Up to 13,000 MB/s |
| Sequential Write | Up to 6,600 MB/s |
| Random Read (4K) | Up to 2,500,000 IOPS |
| Random Write (4K) | Up to 250,000 IOPS |
| Endurance (DWPD) | 1 DWPD |
| Encryption | AES 256-bit, TCG Opal 2.0, SED |
| Data Protection | End-to-End Data Protection (T10 DIF/DIX) |
| Power Loss Protection | Yes (capacitor-based) |
| Operating Temperature | 0°C to 70°C |
| Power Consumption (Active Read) | Approximately 14W |
| Multi-Namespace Support | Yes |
| Namespace Sharing | Yes |
| MTBF | 2,000,000 hours |
| Security Compliance | FIPS 140-2 Level 2 (select variants) |
Frequently Asked Questions about Samsung PM1743 Enterprise SSD (Expected) - 7.68TB
What does the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB do?
At 7.68TB, the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The PCIe 5.0 x4 interface is supported by major server platforms.
What are the headline specs of the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB?
Key specifications for the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB: capacity 7.68TB; form factor E1.S; interface PCIe 5.0 x4; new condition; capacity 7.68TB; interface PCIe 5.0 NVMe; form factor E1.S; read speed 13,000 MB/s; write speed 12,000 MB/s. Manufacturer part number MZWLJ7T6HALA-00B7C-V1. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Samsung PM1743 Enterprise SSD (Expected) - 7.68TB compatible with my infrastructure?
The Samsung PM1743 Enterprise SSD (Expected) - 7.68TB uses a PCIe 5.0 x4 interface in a E1.S form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
