Samsung PM1743 1.92TB E3.S PCIe 5.0 Dell Enterprise SSD

Brand: Samsung | Category: Enterprise SSDs

SKU: SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL | Part #: SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL | MPN: SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL

Contact for Pricing — Request a Quote

Samsung's PM1743 series represents a mature, production-hardened NVMe platform built specifically for the demanding workloads found in modern data centre deployments. The SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL variant arrives in the E3.S 1T form factor—also known as EDSFF (Enterprise and Data Centre SSD Form Factor)—which physically installs into dedicated E3.S backplane slots found on current-generation Dell PowerEdge servers. This 1U-friendly configuration allows a single server to house multiple high-capacity NVMe drives in a dense, hot-swappable arrangement without consuming valuable M.2 real estate or requiring external storage enclosures. Unlike traditional 2.5-inch U.2 or M.2 SSDs, the E3.S design delivers thermal management and mechanical stability at scale, making it the preferred choice for storage architects building out next-generation server infrastructures.

The drive leverages PCIe 5.0 x4 connectivity paired with the NVMe 2.0 protocol, enabling sequential throughput that reaches 14,000 MB/s on reads and 6,000 MB/s on writes. At queue depth 32, the PM1743 sustains these rates without thermal throttling, a critical requirement for workloads that stream large datasets—common in AI training pipelines, database backups, and analytics clusters across the GCC. Random I/O performance is equally compelling: up to 2,500,000 IOPS on 4K read operations and 250,000 IOPS on writes. Samsung packages this performance inside a 1.92TB capacity using their V-NAND TLC technology, striking a practical balance between density and cost-per-GB for mid-to-large capacity tier deployments. The SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL is the form factor of choice when enterprise teams need substantial per-drive capacity without resorting to RAID parity overhead or external SAN complexity.

Reliability and data integrity receive equal engineering attention at Samsung. The drive carries a 1 DWPD (Drive Writes Per Day) endurance rating, translating to approximately 5 years of write cycles under normal enterprise workloads. Hardware-based power loss protection (PLP) safeguards in-flight data should mains power fail unexpectedly—a non-negotiable feature for storage architects designing fault-tolerant systems. The PM1743 also implements end-to-end data protection at the block level and ships with AES 256-bit self-encrypting functionality (TCG Opal 2.0), allowing seamless integration with enterprise key management systems and compliance frameworks. These are the features that separate consumer-grade NVMe from true enterprise-class storage, and they explain why the SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL gets specified into regulated industries and high-availability installations. Temperature tolerance spans 0°C to 70°C in operation and -40°C to 85°C in storage, accommodating both tropical data centre climates in the UAE and the temperature swings of international shipping and logistics.

Integration with Dell infrastructure is seamless. The drive is optimized for Dell PowerEdge platforms and works natively with iDRAC (Integrated Dell Remote Access Controller) and OpenManage Enterprise, meaning system administrators can monitor drive health, view capacity metrics, and perform firmware updates through familiar Dell management dashboards without third-party tools. Storage engineers and infrastructure teams evaluating this drive often come to it after assessing their server backplane capabilities: if a Dell PowerEdge server supports E3.S slots and your workload profile demands 14 GB/s per drive, the PM1743 becomes the obvious specification. The form factor also permits mixed-capacity configurations within the same server—pairing 1.92TB, 3.84TB, and 7.68TB PM1743 drives in a single chassis for tiered performance or capacity layouts without hardware redesign.

Omnixon Global maintains dedicated stock of Samsung enterprise SSDs across our Dubai facility, serving data centre operators, cloud integrators, and enterprise customers throughout the GCC, South Asia, and EMEA regions. The SAMSUNG-PM1743-1.92TB-E3S-PCIE-5-DELL is available for immediate dispatch to Dell PowerEdge deployments requiring E3.S NVMe capacity. For quotation, technical validation, or bulk pricing tied to your infrastructure roadmap, please submit an RFQ through our portal or contact our enterprise storage team directly.

Performance Specifications & Enterprise Storage Positioning

• Sequential read throughput reaches 14,000 MB/s with PCIe 5.0 x4 interface and NVMe 2.0 protocol compliance
• Random I/O performance delivers 2.5M read IOPS and 250K write IOPS at 4K block size, sustaining performance under queue depth 32 without thermal throttling
• Hardware power loss protection (PLP) and end-to-end data protection ensure zero silent data corruption in mission-critical environments
• E3.S 1T form factor integrates directly into Dell PowerEdge E3.S backplane slots, enabling 4+ NVMe drives per server without M.2 congestion or external enclosure dependency
• Samsung V-NAND TLC technology with 1 DWPD endurance rating supports 5-year lifecycles in typical enterprise read-write mixed workloads
• AES 256-bit self-encrypting drive (TCG Opal 2.0) integrates with enterprise key management and compliance frameworks for regulated industries
• Native iDRAC and OpenManage compatibility allows Dell system administrators to monitor, update firmware, and manage capacity through existing management infrastructure
