Kioxia CM7-V 3.200TB E3.S Dual x2 SSD
Brand: Kioxia | Category: Enterprise SSDs
SKU: KCM7XVJE3T20 | Part #: KCM7XVJE3T20 | MPN: KCM7XVJE3T20
Contact for Pricing — Request a Quote
About the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD
The Kioxia CM7-V 3.200TB E3.S Dual x2 SSD addresses read-intensive cache layers delivering up to 2,500,000 random read IOPS, write-intensive log tiers supporting up to 350,000 random write IOPS, and mixed-workload primary storage with sequential read throughput reaching 14,000 MB/s. This enterprise-class drive combines PCIe 5.0 x2 and NVMe 1.4 interfaces with dual-port connectivity, positioning it as a high-performance, mission-critical storage component for demanding data center environments. Built on Kioxia BiCS FLASH 3D TLC technology with end-to-end T10 PI data protection, the CM7-V series delivers both speed and reliability for infrastructure-heavy deployments.
Storage architects and IT procurement teams standardizing on OCP NVMe Cloud SSD Specification–compliant hardware will find the Kioxia CM7-V (part number KCM7XVJE3T20) purpose-built for hyperscale and enterprise cloud environments. The 3.200TB capacity in E3.S 1T (EDSFF) form factor supports multiple namespaces and zoned namespace capabilities, enabling fine-grained workload isolation and resource allocation across virtual and containerized applications. With an active power profile capped at 25W and a 1 DWPD write endurance rating backed by approximately 6,400 TBW, this drive balances operational efficiency with sustained performance in round-the-clock enterprise service. Operating across 0°C to 70°C ensures compatibility with diverse thermal environments across modern data centers.
Omnixon Global supplies Kioxia enterprise storage solutions to enterprises and integrators across the Gulf region. To request a formal quotation for the CM7-V 3.200TB E3.S Dual x2 SSD or discuss volume pricing and technical specifications for your infrastructure roadmap, contact our B2B sales team in Dubai today.
Technical Specifications
| Brand | Kioxia |
| Category | Enterprise SSDs |
| SKU | KCM7XVJE3T20 |
| Part Number | KCM7XVJE3T20 |
| Condition | New |
| Capacity | 3.200TB |
| Form Factor | E3.S |
| Interface | Dual x2 |
| Speed | Read:14000 Mb/s,Write:6750 Mb/s |
| Manufacturer Part Number | KCM7XVJE3T20 |
| Series | CM7-V |
| Capacity | 3.200 TB |
| Form Factor | E3.S 1T (EDSFF) |
| Interface | PCIe 5.0 x2, NVMe 1.4 |
| Ports | Dual Port |
| NAND Flash Type | Kioxia BiCS FLASH 3D TLC |
| Sequential Read Throughput | Up to 14,000 MB/s |
| Sequential Write Throughput | Up to 7,000 MB/s |
| Random Read IOPS | Up to 2,500,000 IOPS (4KB) |
| Random Write IOPS | Up to 350,000 IOPS (4KB) |
| Power Consumption (Active) | Up to 25 W |
| End-to-End Data Protection | Yes (T10 PI compatible) |
| Namespace Support | Multiple Namespaces |
| Zoned Namespace (ZNS) Support | Yes |
| OCP NVMe Cloud SSD Specification | Compliant |
| DWPD (Drive Writes Per Day) | 1 DWPD |
| TBW (Total Bytes Written) | Approximately 6,400 TBW |
| Operating Temperature | 0°C to 70°C |
| Encryption | Self-Encrypting Drive (SED), AES 256-bit |
Frequently Asked Questions about Kioxia CM7-V 3.200TB E3.S Dual x2 SSD
What does the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD do?
At 3.200TB, the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The Dual x2 interface is supported by major server platforms.
What are the headline specs of the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD?
Key specifications for the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD: capacity 3.200TB; form factor E3.S; interface Dual x2; Manufacturer support support; new condition; model CM7-V; capacity 3.200TB; interface Dual x2; form factor E3.S; sequential read speed 14000 Mb/s; sequential write speed 6750 Mb/s. Manufacturer part number KCM7XVJE3T20. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the Kioxia CM7-V 3.200TB E3.S Dual x2 SSD compatible with my infrastructure?
The Kioxia CM7-V 3.200TB E3.S Dual x2 SSD uses a Dual x2 interface in a E3.S form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
