Kingston DC2000B 240GB PCIe 4.0 NVMe M.2 2280 Enterprise SSD, No Heatsink (SEDC2000BYM8/240G)

Kingston DC2000B 240GB PCIe 4.0 NVMe M.2 2280 Enterprise SSD, No Heatsink (SEDC2000BYM8/240G)

PCIe 4.0 NVMe boot and system storage with power loss protection in a compact M.2 2280 form factor.

The Kingston SEDC2000BYM8/240G is a 240GB DC2000B enterprise SSD in the M.2 2280 form factor with a PCIe 4.0 x4 NVMe interface and 3D TLC NAND. It delivers sequential read/write of up to 4500/400 MBs and steady-state 4k read/write of 260000/18000 IOPS. Power loss protection and enterprise SMART tools are built in, and this non-heatsink version measures 80mm x 22mm x 3.5mm.

Perfect for

• Server boot drives hosting the operating system on enterprise servers with M.2 2280 PCIe slots.
• Virtualisation hosts providing fast local boot storage for hypervisor installations.
• Data centre infrastructure serving as system storage in rack servers across the data centre.
• Edge and branch servers supplying compact NVMe system storage in space-constrained deployments.

Why buyers choose this model

• PCIe 4.0 NVMe speed. Sequential read/write reaches 4500/400 MBs over a PCIe 4.0 x4 NVMe interface.
• Power loss protection. Onboard power caps provide power loss protection.
• Rated endurance. The 240GB model is rated for 175 TBW, or 0.4 DWPD over 5 years.
• Low latency. Average read latency is 70µs and average write latency is 53µs.
• Enterprise SMART monitoring. SMART tools track reliability, usage statistics, SSD life remaining, wear levelling and temperature.

Key specifications

Specifications as published by Kingston for this part number. The full list is in the Specifications tab.
