Huawei UPS5000-E-600K-FM Modular UPS
Brand: Huawei | Category: UPS & Power Protection
SKU: H-UPS5000-E-600K-FM | Part #: UPS5000-E-600K-FM | MPN: UPS5000-E-600K-FM
Contact for Pricing — Request a Quote
About the Huawei UPS5000-E-600K-FM Modular UPS
The Huawei UPS5000-E-600K-FM Modular UPS accepts three-phase AC input across 380 / 400 / 415 V with a wide frequency range of 45–55 Hz, delivering 600 kVA / 600 kW of rated output capacity at 1.0 power factor. This double-conversion online topology (VFI) ensures zero-millisecond transfer time from mains to battery, guaranteeing uninterrupted power to mission-critical infrastructure without any perceptible interruption.
Engineered by Huawei for enterprise data centres and large-scale industrial deployments, the UPS5000-E-600K-FM combines modular architecture with hot-swap capability, enabling online capacity expansion and concurrent maintainability without shutdown. Double-conversion efficiency reaches up to 96% at full load, while ECO mode delivers up to 99% efficiency for cost-sensitive continuous operation. Input THDi remains below 3% at full load thanks to an active front-end rectifier, and output voltage THD stays below 1% for linear loads and below 3% for non-linear loads. The system supports external VRLA or lithium-ion battery cabinets and enables parallel redundancy across multiple frames for N+X fault tolerance. This modular design appeals to IT procurement teams and infrastructure architects seeking scalable, high-availability power solutions. Communication interfaces include dry contacts, RS485, Modbus, and SNMP via network management module, integrating seamlessly into existing monitoring ecosystems. IP20 protection class and intelligent variable-speed fan cooling ensure reliable operation in controlled environments. Contact Omnixon Global for a detailed RFQ on the UPS5000-E-600K-FM and discover how Huawei's modular UPS platform can elevate your power protection strategy.
Key Specifications
- Topology: Double-conversion online (VFI, Voltage and Frequency Independent)
- Rated Output Capacity: 600 kVA / 600 kW at 1.0 power factor
- Transfer Time (Mains to Battery): 0 ms
- Double-Conversion Efficiency (Full Load): Up to 96%; ECO Mode up to 99%
- Input Voltage: 380 / 400 / 415 V AC (3P+N+PE); frequency 45–55 Hz wide range
- Output Voltage THD: < 1% linear load / < 3% non-linear load
Technical Specifications
| Brand | Huawei |
| Category | UPS & Power Protection |
| SKU | H-UPS5000-E-600K-FM |
| Part Number | UPS5000-E-600K-FM |
| Condition | New |
| Capacity | 600 kVA |
| Manufacturer Part Number | UPS5000-E-600K-FM |
| Topology | Double-conversion online (VFI, Voltage and Frequency Independent) |
| Rated Output Capacity | 600 kVA / 600 kW |
| Output Power Factor | 1.0 |
| System Architecture | Hot-swap modular; online capacity expansion and concurrent maintainability |
| Double-Conversion Efficiency (Full Load) | Up to 96% |
| ECO Mode Efficiency | Up to 99% |
| Input Voltage (3-phase) | 380 / 400 / 415 V AC (3P+N+PE) |
| Input Frequency | 45–55 Hz (wide range) / 50 Hz nominal |
| Input THDi | < 3% (at full load, with active front-end rectifier) |
| Output Voltage | 380 / 400 / 415 V AC (3P+N+PE) |
| Output Frequency | 50 Hz ± 0.1 Hz (inverter mode) |
| Output Voltage THD | < 1% (linear load) / < 3% (non-linear load) |
| Transfer Time (Mains to Battery) | 0 ms (double-conversion, uninterrupted) |
| Parallel Redundancy Support | Yes; multiple frames can be paralleled for N+X redundancy |
| Battery Compatibility | External battery cabinet (VRLA or lithium-ion, configured per deployment) |
| Communication Interfaces | Dry contacts, RS485, Modbus, SNMP (via network management module) |
| Protection Class | IP20 |
| Cooling Method | Forced air cooling (intelligent variable-speed fans) |
Frequently Asked Questions about Huawei UPS5000-E-600K-FM Modular UPS
What does the Huawei UPS5000-E-600K-FM Modular UPS do?
The Huawei UPS5000-E-600K-FM Modular UPS delivers conditioned, backed-up power for server rooms and data-center racks. Use cases include short-term ride-through during grid sag/spike events, graceful shutdown of critical compute, and runtime extension via external battery packs.
What are the headline specs of the Huawei UPS5000-E-600K-FM Modular UPS?
Key specifications for the Huawei UPS5000-E-600K-FM Modular UPS: capacity 600 kVA; 3 years support; new condition; support 3 years standard (manufacturer). Manufacturer part number UPS5000-E-600K-FM. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
