Brand: APC | Category: UPS & Power Protection
SKU: APTF10KW01 | Part #: APTF10KW01 | MPN: APTF10KW01
Contact for Pricing — Request a Quote
The APC APTF10KW01 is a 10 kVA rack-mountable isolation transformer for UPS and power protection installations. It is rated for a 10,000 VA load at a nominal 230 V input and 230 V output, with a maximum input current and total current draw of 60 A per phase.
Input is hard wired, either 3-wire 2PH + G or 3-wire 1PH + N + G. Output is a single hard-wired 3-wire connection (H, N + G). The unit operates from 0 to 40 °C and 0 to 95% relative humidity, and can be stored from -25 to 65 °C. It measures 432 mm wide, 749 mm deep and 175 mm high, weighs 100 kg and is finished in black. Listed certifications include CE, UL Listed, CSA, VDE, GOST, C-tick, EN 55022 Class A, EN 55024, EN 61000-3-2 and EN 61000-3-3.
It is typically installed in data centre and server room racks as part of a hard-wired power distribution and protection setup.
Send the part number through our RFQ form and our team will reply within 48 hours.
| Brand | APC |
| Category | UPS & Power Protection |
| SKU | APTF10KW01 |
| Part Number | APTF10KW01 |
| Condition | New |
| Output connections | 1x Hard Wire 3-wire (H N + G) |
| Input connection type | Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G) |
| Maximum total current draw per phase | 60 A |
| Maximum input current per phase | 60 A |
| Load capacity | 10000 VA |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
| Product colour | Black |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Storage temperature (T-T) | -25 - 65 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Weight | 100 kg |
| Height | 175 mm |
| Depth | 749 mm |
| Width | 432 mm |
| Certification | C-tick,CE,CSA,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,GOST,UL Listed,VDE |
The APC APTF10KW01 WW 10KVA Isolation Transformer Rack-Mountable delivers conditioned, backed-up power for server rooms and data-center racks. Use cases include short-term ride-through during grid sag/spike events, graceful shutdown of critical compute, and runtime extension via external battery packs.
Key specifications for the APC APTF10KW01 WW 10KVA Isolation Transformer Rack-Mountable: new condition; output connections 1x Hard Wire 3-wire (H N + G); input connection type Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G); maximum total current draw per phase 60 A; maximum input current per phase 60 A; load capacity 10000 VA; nominal output voltage 230 V. Manufacturer part number APTF10KW01. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
