Mellanox ConnectX-7 Single-Port 200GbE/HDR InfiniBand QSFP112 PCIe 5.0 OCP 3.0 Adapter
Brand: Mellanox | Category: Network Adapters & NICs
SKU: MCX715105AS-HEAT | Part #: MCX715105AS-HEAT | MPN: MCX715105AS-HEAT
Contact for Pricing — Request a Quote
About the Mellanox ConnectX-7 Single-Port 200GbE/HDR InfiniBand QSFP112 PCIe 5.0 OCP 3.0 Adapter
The Mellanox ConnectX-7 Single-Port 200GbE/HDR InfiniBand QSFP112 PCIe 5.0 OCP 3.0 Adapter from Mellanox is enterprise-grade Network Adapters & NICs hardware built for data centers. The Mellanox ConnectX-7 Single-Port 200GbE/HDR InfiniBand adapter delivers high-performance interconnect in an OCP 3.0 mezzanine form factor, enabling deployment in space-constrained enterprise servers where PCIe slot availability is limited. This adapter supports both 200GbE Ethernet and HDR InfiniBand protocols on a single QSFP112 port, with PCIe 5.0 x16 connectivity for maximum bandwidth utilization in next-generation GPU and compute clusters. Available in brand new condition. Mellanox network adapters & nics products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Mellanox |
| Category | Network Adapters & NICs |
| SKU | MCX715105AS-HEAT |
| Part Number | MCX715105AS-HEAT |
| Condition | New |
| Model | ConnectX-7 Single-Port 200GbE/HDR InfiniBand |
| Form Factor | OCP 3.0 Mezzanine |
| Port Count | 1 |
| Port Speed - Ethernet | 200 Gbps |
| Port Speed - InfiniBand | HDR (200 Gbps) |
| Port Interface | QSFP112 |
| PCIe Generation | 5.0 |
| PCIe Lane Count | x16 |
| Protocol Support | Ethernet, InfiniBand, RoCE v2 |
| RDMA Support | Yes (RoCE v2) |
| Memory | Integrated on-adapter DDR4 |
| Max Frame Size | 9216 bytes |
| Adaptive Routing | Supported |
| Congestion Control | Supported |
| Operating Temperature Range | 0–55°C |
| Storage Temperature Range | -40–70°C |
| Launch Date | Q2 2022 |
