Western Digital Ultrastar DC HC690 32TB UltraSMR HDD
Brand: Western Digital | Category: Enterprise HDDs
SKU: WEST-WUH722632ALE6L4 | Part #: WUH722632ALE6L4 | MPN: WUH722632ALE6L4
Contact for Pricing — Request a Quote
About the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD
The Western Digital Ultrastar DC HC690 is a 32TB enterprise hard drive using UltraSMR shingled magnetic recording to achieve industry-leading capacity per spindle. Combining ePMR energy-assisted recording, OptiNAND, and an advanced large-block encoding scheme, it maximizes density for sequential-write capacity tiers in hyperscale infrastructure.
The helium-sealed design supports always-on operation with a 2.5-million-hour rating and high annual workload tolerance. UltraSMR is optimized for sequential and zoned write patterns common in object storage and archive systems, where host-managed or device-managed zoning extracts the full capacity advantage over conventional recording.
Ideal for
- Hyperscale object and archive storage
- Sequential-write capacity tiers
- Cold and active-archive data pools
- Distributed file-system capacity nodes
- Backup and long-retention repositories
Technical specifications
| Manufacturer | Western Digital |
| Series | Ultrastar DC HC690 |
| Part Number | WUH722632ALE6L4 |
| Capacity | 32 TB |
| Recording Technology | UltraSMR with ePMR + OptiNAND |
| Form Factor | 3.5-inch |
| Interface | SATA 6Gb/s |
| Rotational Speed | 7,200 RPM |
| Cache | 512 MB |
| Platform | HelioSeal (helium-sealed) |
| Sustained Transfer Rate | Up to 290 MB/s |
| Loaded Workload | 550 TB/year |
| MTBF | 2.5 million hours |
| Zoning | Host-managed / device-managed SMR |
| Sector Size | 512e / 4Kn |
| Encryption Options | SE / SED / TCG |
| Operating Temperature | 5°C to 60°C |
Available from Omnixon Global. Submit an RFQ and our team will confirm configuration and availability for your order.
Technical Specifications
| Brand | Western Digital |
| Category | Enterprise HDDs |
| SKU | WEST-WUH722632ALE6L4 |
| Part Number | WUH722632ALE6L4 |
| Condition | New |
| Series | Ultrastar DC HC690 |
| Capacity | 32 TB |
| Recording Technology | UltraSMR with ePMR + OptiNAND |
| Form Factor | 3.5-inch |
| Interface | SATA 6Gb/s |
| Rotational Speed | 7,200 RPM |
| Cache | 512 MB |
| Platform | HelioSeal (helium-sealed) |
| Sustained Transfer Rate | Up to 290 MB/s |
| Loaded Workload | 550 TB/year |
| MTBF | 2.5 million hours |
| Zoning | Host-managed / device-managed SMR |
| Sector Size | 512e / 4Kn |
| Encryption Options | SE / SED / TCG |
| Operating Temperature | 5°C to 60°C |
Frequently Asked Questions about Western Digital Ultrastar DC HC690 32TB UltraSMR HDD
What does the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD do?
the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. It is supported by major server platforms.
What does the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD do?
the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. It is supported by major server platforms.
What are the headline specs of the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD?
Key specifications for the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD: new condition; manufacturer Western Digital; series Ultrastar DC HC690; part number WUH722632ALE6L4; capacity 32 TB; recording technology UltraSMR with ePMR + OptiNAND; form factor 3.5-inch. Manufacturer part number WUH722632ALE6L4. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
What are the headline specs of the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD?
Key specifications for the Western Digital Ultrastar DC HC690 32TB UltraSMR HDD: new condition; manufacturer Western Digital; series Ultrastar DC HC690; part number WUH722632ALE6L4; capacity 32 TB; recording technology UltraSMR with ePMR + OptiNAND; form factor 3.5-inch. Manufacturer part number WUH722632ALE6L4. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
