WD Ultrastar DC HC670 Enterprise HDD (Expected) - 22TB

Brand: Western Digital | Category: Enterprise HDDs

SKU: WUH722022BALE6L4 | Part #: WUH722022BALE6L4 | MPN: WUH722022BALE6L4

Contact for Pricing — Request a Quote

The WD Ultrastar DC HC670 operates at 7200 RPM with a formatted capacity of 22 TB, positioning it as a high-capacity mid-tier drive for organisations managing large sequential workloads across distributed storage clusters. This combination of speed and density makes the WUH722022BALE6L4 useful for environments where storage architects need to balance cost-per-terabyte against reasonable I/O throughput without investing in the power and cooling overhead of SSD-dominant architectures.

Western Digital engineered the Ultrastar DC HC670 around HelioSeal technology, a helium-sealed enclosure that reduces air density inside the drive and allows nine platters to spin efficiently at 7200 RPM while consuming only 7.2 W during active read and write operations. That power efficiency matters when you're deploying hundreds or thousands of drives in a data centre—even small per-drive reductions compound into measurable OPEX savings across a three-to-five-year procurement cycle. The integration of OptiNAND technology, which adds an embedded iNAND UFS flash component, improves cache performance and data integrity during power loss scenarios, a feature that storage architects increasingly specify for mission-critical warm storage tiers.

Storage performance on the WUH722022BALE6L4 reaches up to 269 MB/s sustained transfer rate from buffer to media, coupled with a 512 MB DRAM cache that smooths burst traffic patterns common in backup windows and batch analytics jobs. The drive's rated workload capacity sits at 550 TB per year annualized, suited to always-on enterprise deployments rather than occasional-use archive. Reliability metrics include a mean time between failure (MTBF) of 2,500,000 hours and non-recoverable read errors rated at just one per 10¹⁵ bits read—specifications that meet the durability expectations of data centre operators who cannot afford media failures to cascade into costly recovery operations or service interruptions. Rotational vibration compensation built into the Ultrastar platform reduces the acoustic and mechanical stress that traditionally plagues dense multi-drive enclosures, a practical advantage when cooling systems and drive proximity create resonance issues.

Network and storage engineers commonly deploy the Western Digital Ultrastar DC HC670 in tiered storage architectures where cold or warm data must be accessible without the latency penalty of tape or the power penalty of all-flash systems. Financial institutions, research organisations, and cloud service providers use drives with this capacity and speed profile to feed distributed analytics pipelines, support large-scale archival repositories, and provide cost-effective redundancy for RAID-protected NAS and SAN environments. The non-SED variant of part number WUH722022BALE6L4 integrates directly into existing infrastructure without requiring additional encryption overhead, though security-conscious buyers should evaluate their compliance mandates before committing to a non-encrypted drive in high-security deployments.

Operating across a temperature range of 0°C to 60°C and drawing only 0.9 W during standby, the Ultrastar DC HC670 adapts to both controlled data centre environments and edge deployments where thermal management may be less predictable. The 3.5-inch form factor ensures compatibility with standard rack-mounted storage arrays, eliminating the need for mechanical redesign or costly adapter solutions. Western Digital's track record in enterprise markets and the broad OEM validation of the Ultrastar line provide procurement confidence for large-scale roll-outs, particularly in regions where supply chain continuity and local support matter.

Enterprise Storage Positioning and Deployment Context

• 22 TB formatted capacity at 7200 RPM suits warm-data and sequential-access workloads requiring sub-second latency but not NVMe speeds
• HelioSeal helium-sealed enclosure and OptiNAND embedded flash reduce operational power draw and improve power-loss resilience across large deployments
• Sustained transfer rate of 269 MB/s and 512 MB cache support consistent performance during backup windows, batch jobs, and multi-stream analytics queries
• 550 TB/year workload rating and 2.5 million-hour MTBF align with continuous-operation data centre environments and RAID-protected storage systems
• 3.5-inch SATA 6 Gb/s interface integrates into existing NAS, SAN, and storage appliance architectures without firmware or driver complications
• Non-SED configuration reduces cost and compatibility friction for organisations without strict encryption mandates, while supporting standard AES encryption at the storage controller level

Omnixon Global stocks the WD Ultrastar DC HC670 (WUH722022BALE6L4) as part of a curated selection of enterprise storage solutions serving data centres, AI infrastructure labs, and large-scale IT operations across the GCC, South Asia, and Europe. Our regional presence in Dubai positions us to provide rapid availability, technical pre-sales support, and logistics coordination for procurement teams evaluating this drive for production deployments. If your organisation is planning a storage expansion, comparing cost-per-terabyte across drive generations, or building out a tiered architecture, contact our sales team to discuss configuration options, volume pricing, and delivery timelines tailored to your project schedule.
