TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch
Brand: TP-Link | Category: Network Switches
SKU: TPLI-TLSX6632YF | Part #: TL-SX6632YF | MPN: TL-SX6632YF
Contact for Pricing — Request a Quote
About the TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch
The TP-Link JetStream TL-SX6632YF is a high-performance 1U core/aggregation switch featuring 32× 100G QSFP28 ports, delivering a 6.4 Tbps non-blocking switching fabric with a forwarding rate of 4.76 Bpps. Each QSFP28 port supports 100GbE, 40GbE (with QSFP+ optics), and breakout to 4× 25G or 4× 10G using QSFP28 breakout cables, providing exceptional port density flexibility. This makes the SX6632YF capable of serving as a spine switch in a leaf-spine data center fabric or as the campus network core aggregating multiple 10G/25G distribution switches.
The switch runs a full L3 feature set including OSPFv2/v3, BGP, IS-IS, static routing, VRF-Lite for traffic isolation, and ECMP for load balancing across multiple uplinks. Its VXLAN support enables overlay network construction for multi-tenant data center environments and east-west traffic segmentation. PIM-SM/DM multicast routing handles high-bandwidth video and financial market data distribution. MPLS support broadens its applicability to service provider edge and large enterprise WAN aggregation roles.
The TL-SX6632YF is managed via the Omada SDN controller at the infrastructure level while also supporting full CLI management via SSH and console port for network engineers requiring granular control. Hardware-based forwarding ensures line-rate performance across all 32 ports simultaneously. Redundant hot-swappable power supplies and front-to-rear airflow (with reversible fan tray options) address data center operational requirements for high availability and thermal management.
Ideal for
- Enterprise data center spine switch in leaf-spine fabric architecture
- Large university or hospital campus core network switch
- 100G backbone aggregation replacing aging 10G core infrastructure
- Multi-tenant data center VXLAN overlay fabric spine
- Financial services high-throughput low-latency core switch
- Service provider edge aggregation with BGP routing support
Technical specifications
| Manufacturer | TP-Link |
| Part Number | TL-SX6632YF |
| Form Factor | 1U Rack-Mount |
| QSFP28 Ports | 32× 100G QSFP28 (backward compatible with 40G QSFP+) |
| Breakout Support | 4× 25G or 4× 10G per port via breakout cable |
| Switching Capacity | 6.4 Tbps |
| Forwarding Rate | 4.76 Bpps |
| MAC Address Table | 128K entries |
| IPv4 Route Table | 128K entries (hardware TCAM) |
| IPv6 Route Table | 64K entries |
| Layer | L3 (Full) |
| Routing Protocols | Static, OSPFv2/v3, BGP-4, IS-IS, RIPv1/v2, ECMP |
| Overlay | VXLAN (EVPN control plane) |
| VRF | VRF-Lite (multi-tenant routing isolation) |
| Multicast Routing | PIM-SM, PIM-DM, IGMP v1/v2/v3, MLD |
| MPLS | MPLS forwarding support |
| High Availability | VRRP, BFD, redundant hot-swap PSU |
| Management | Omada SDN, CLI (SSH/Console), SNMP v1/v2c/v3, NETCONF, OpenConfig |
| Power Supplies | 2× hot-swappable redundant PSU (1+1) |
| Airflow | Front-to-rear (reversible fan tray option) |
| Fans | Hot-swappable fan modules |
| Dimensions | 440 × 460 × 44 mm (1U) |
| Operating Temperature | 0°C to 45°C |
Available from Omnixon Global. Submit an RFQ and our team will confirm configuration and availability for your order.
Technical Specifications
| Brand | TP-Link |
| Category | Network Switches |
| SKU | TPLI-TLSX6632YF |
| Part Number | TL-SX6632YF |
| Condition | New |
| Form Factor | 1U Rack-Mount |
| QSFP28 Ports | 32× 100G QSFP28 (backward compatible with 40G QSFP+) |
| Breakout Support | 4× 25G or 4× 10G per port via breakout cable |
| Switching Capacity | 6.4 Tbps |
| Forwarding Rate | 4.76 Bpps |
| MAC Address Table | 128K entries |
| IPv4 Route Table | 128K entries (hardware TCAM) |
| IPv6 Route Table | 64K entries |
| Layer | L3 (Full) |
| Routing Protocols | Static, OSPFv2/v3, BGP-4, IS-IS, RIPv1/v2, ECMP |
| Overlay | VXLAN (EVPN control plane) |
| VRF | VRF-Lite (multi-tenant routing isolation) |
| Multicast Routing | PIM-SM, PIM-DM, IGMP v1/v2/v3, MLD |
| MPLS | MPLS forwarding support |
| High Availability | VRRP, BFD, redundant hot-swap PSU |
| Management | Omada SDN, CLI (SSH/Console), SNMP v1/v2c/v3, NETCONF, OpenConfig |
| Power Supplies | 2× hot-swappable redundant PSU (1+1) |
| Airflow | Front-to-rear (reversible fan tray option) |
| Fans | Hot-swappable fan modules |
| Dimensions | 440 × 460 × 44 mm (1U) |
| Operating Temperature | 0°C to 45°C |
Frequently Asked Questions about TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch
What does the TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch do?
The TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
What are the headline specs of the TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch?
Key specifications for the TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch: new condition; manufacturer TP-Link; part number TL-SX6632YF; form factor 1U Rack-Mount; qsfp28 ports 32× 100G QSFP28 (backward compatible with 40G QSFP+); breakout support 4× 25G or 4× 10G per port via breakout cable; switching capacity 6.4 Tbps. Manufacturer part number TL-SX6632YF. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch compatible with my infrastructure?
The TP-Link JetStream TL-SX6632YF 32-Port 100G QSFP28 L3 Managed Core Switch interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
