Synology RackStation RS3621xs+ 12-Bay NAS
Brand: Synology | Category: Storage Systems
SKU: RS3621xs+ | Part #: RS3621xs+ | MPN: RS3621xs+
Contact for Pricing — Request a Quote
About the Synology RackStation RS3621xs+ 12-Bay NAS
The Synology RackStation RS3621xs+ is a 12-bay 2U rackmount NAS designed for enterprise-scale data management, backup, and surveillance infrastructure. Built on the AMD EPYC processor architecture, it delivers high-throughput performance with support for 10GbE and 25GbE connectivity, enabling rapid data ingestion and retrieval across distributed networks.
The system accommodates mixed storage configurations with support for both 3.5" and 2.5" drives, allowing organizations to balance capacity and performance according to workload requirements. Advanced RAID functionality, including RAID 6, RAID 10, and SHR configurations, ensures data protection against multi-drive failures while maintaining operational continuity in mission-critical environments.
DSM 7 operating system provides centralized management, replication, and disaster recovery capabilities. The RackStation RS3621xs+ integrates seamlessly into virtualized infrastructures and supports iSCSI, NFS, and SMB protocols for heterogeneous enterprise environments requiring flexible storage access patterns.
Ideal for
- Centralized backup infrastructure for multi-site organizations with native support for Hyper-V, VMware, and physical server environments
- Surveillance system hub for IP camera deployments requiring continuous recording and archival of HD/4K video streams
- High-performance shared storage for creative workflows including video editing, 3D rendering, and media production
- Disaster recovery and business continuity replication hub between geographically distributed data centers
- Archival storage platform for compliance and long-term data retention with configurable tiering policies
- iSCSI SAN backend for virtualization environments requiring block-level storage consolidation
Technical specifications
| Manufacturer | Synology |
| Model | RS3621xs+ |
| Form Factor | 2U Rackmount |
| Drive Bays | 12 |
| Supported Drive Types | 3.5" and 2.5" SATA/SAS |
| Processor | AMD EPYC 7002 series |
| CPU Cores | 8 |
| Memory | 16GB DDR4 ECC (2x8GB RDIMM, upgradeable to 192GB) |
| Memory Slots | 6 |
| Maximum Memory | 192GB |
| Network Interfaces | 4x 1GbE RJ45, 2x 10/25GbE SFP28 |
| Expansion Slots | 2x PCIe 3.0 x16 |
| RAID Support | RAID 0, 1, 5, 6, 10, SHR, SHR-2 |
| System Memory Type | UDIMM |
| Operating System | DSM 7 |
| Power Consumption | 230W (typical) |
| Thermal Design | 2x 120mm fans, front intake/rear exhaust |
| Dimensions (WxDxH) | 483 x 733 x 89mm |
| Weight | Approximately 26kg (empty) |
| Redundancy Features | Redundant power supply option, hot-swappable drives |
Available from Omnixon Global. Submit an RFQ and our team will confirm configuration and availability for your order.
Technical Specifications
| Brand | Synology |
| Category | Storage Systems |
| SKU | RS3621xs+ |
| Part Number | RS3621xs+ |
| Condition | New |
| Model | RS3621xs+ |
| Form Factor | 2U Rackmount |
| Drive Bays | 12 |
| Supported Drive Types | 3.5" and 2.5" SATA/SAS |
| Processor | AMD EPYC 7002 series |
| CPU Cores | 8 |
| Memory | 16GB DDR4 ECC (2x8GB RDIMM, upgradeable to 192GB) |
| Memory Slots | 6 |
| Maximum Memory | 192GB |
| Network Interfaces | 4x 1GbE RJ45, 2x 10/25GbE SFP28 |
| Expansion Slots | 2x PCIe 3.0 x16 |
| RAID Support | RAID 0, 1, 5, 6, 10, SHR, SHR-2 |
| System Memory Type | UDIMM |
| Operating System | DSM 7 |
| Power Consumption | 230W (typical) |
| Thermal Design | 2x 120mm fans, front intake/rear exhaust |
| Dimensions (WxDxH) | 483 x 733 x 89mm |
| Weight | Approximately 26kg (empty) |
| Redundancy Features | Redundant power supply option, hot-swappable drives |
Frequently Asked Questions about Synology RackStation RS3621xs+ 12-Bay NAS
What does the Synology RackStation RS3621xs+ 12-Bay NAS do?
the Synology RackStation RS3621xs+ 12-Bay NAS suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. It is supported by major server platforms.
What are the headline specs of the Synology RackStation RS3621xs+ 12-Bay NAS?
Key specifications for the Synology RackStation RS3621xs+ 12-Bay NAS: new condition; manufacturer Synology; model RS3621xs+; form factor 2U Rackmount; drive bays 12; supported drive types 3.5" and 2.5" SATA/SAS; processor AMD EPYC 7002 series. Manufacturer part number RS3621xs+. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
