MikroTik RB5009UPr+S+OUT Router

The MikroTik RB5009UPr+S+OUT is the hardened outdoor variant of the acclaimed RB5009 platform, purpose-built for enterprise edge installations where exposure to harsh environmental conditions is unavoidable. It combines the same high-performance Marvell Armada 88F7040 quad-core ARMv8 1.4 GHz architecture with a ruggedized IP66-rated weatherproof enclosure, making it equally capable in open-air industrial sites, telecommunications tower bases, transportation hubs, and remote monitoring installations. The unit delivers gigabit throughput across eight Ethernet ports with full PoE-out capability on all RJ45 interfaces (802.3bt/at/af), allowing it to directly power downstream surveillance cameras, wireless access points, and IoT sensors without additional injectors or switches.

At the uplink tier, the RB5009UPr+S+OUT incorporates a 10G SFP+ cage providing high-bandwidth fiber or DAC connectivity back to the core network, enabling the unit to serve as a primary edge aggregation point rather than merely a distribution device. The router runs RouterOS v7, MikroTik's mature and feature-rich network operating system, delivering advanced routing protocols (OSPF, BGP, MPLS), firewall, NAT, VPN (IPsec, WireGuard, OpenVPN, L2TP), traffic shaping, and CAPsMAN wireless management from a single unified CLI and Winbox interface. Onboard 1 GB RAM and 512 MB NAND flash support demanding routing tables and logging without external storage.

The outdoor enclosure is engineered with integrated mounting hardware for pole or wall attachment, UV-resistant materials, and a wide operating temperature range, addressing the failure modes that typically afflict indoor-class hardware deployed outside. A dedicated passive Power over Ethernet input on a secondary port provides convenient single-cable power and management uplink in installations where running AC power is impractical. This combination of PoE budget, 10G uplink, RouterOS flexibility, and environmental hardening positions the RB5009UPr+S+OUT as one of the most capable purpose-built outdoor routers available to enterprise and industrial network operators.

Ideal for

• Wireless ISP (WISP) tower base-station aggregation routing multiple sector radios over PoE with 10G fiber backhaul to the core
• Outdoor industrial IoT gateway connecting PoE-powered sensors, cameras, and edge compute nodes in manufacturing yards or substations
• Transportation and smart-city infrastructure edge nodes linking traffic cameras, signage, and control systems over ruggedized fiber rings
• Remote enterprise branch or construction-site connectivity providing full BGP/OSPF routing, VPN, and firewall without an indoor equipment room
• Campus outdoor distribution layer aggregating multiple outdoor access points via 802.3bt PoE and feeding a 10G uplink to the campus core
• Critical infrastructure perimeter security network hosting PoE PTZ cameras and access-control panels with hardware-accelerated IPsec tunnels back to the NOC

Technical specifications

Available from Omnixon Global. Submit an RFQ and our team will confirm configuration and availability for your order.
