MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA)
Brand: MikroTik | Category: Wireless Access Points
SKU: MIKR-D53G5HACD2HNDTCRG502QEA | Part #: D53G-5HacD2HnD-TC&RG502Q-EA | MPN: D53G-5HacD2HnD-TC&RG502Q-EA
Contact for Pricing — Request a Quote
About the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA)
The MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) is a purpose-built 5G gateway and Wi-Fi 6 router designed for enterprise branch offices, retail sites, and pop-up deployments that demand reliable, high-throughput connectivity without dependence on fixed-line infrastructure. At its core sits the Qualcomm-based Quectel RG502Q-EA Sub-6GHz 5G modem supporting 3GPP Release 15, capable of theoretical downlink speeds exceeding 4 Gbps on 5G NR and backward-compatible with LTE-A, LTE-A Pro, and 3G networks. The device runs RouterOS v7, MikroTik's mature network operating system, exposing the full suite of enterprise routing features including BGP, OSPF, MPLS, VLAN segmentation, firewall, and advanced QoS — all manageable via Winbox, WebFig, SSH, or the MikroTik mobile app.
Ideal for
- Enterprise branch office primary WAN via 5G NR with automatic failover to wired broadband using RouterOS bonding and scripted failover policies
- Retail pop-up store or seasonal outlet requiring rapid deployment of secure Wi-Fi 6 and cellular-backed internet without ISP provisioning lead times
- Construction site or temporary field office needing ruggedized, carrier-agnostic connectivity with dual-SIM failover between two mobile network operators
- SD-WAN edge node aggregating 5G and Ethernet uplinks with VLAN segmentation for POS systems, guest Wi-Fi, and back-office traffic isolation
- Event venue or trade-show booth demanding high-density Wi-Fi 6 client support backed by 5G uplink to handle simultaneous video conferencing and cloud applications
- Out-of-band management gateway providing cellular-backed remote access to network infrastructure when primary WAN circuits fail at distributed enterprise sites
Technical specifications
| Manufacturer | MikroTik |
| Model | Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) |
| 5G Modem | Quectel RG502Q-EA (Qualcomm SDX55) |
| 5G Standard | 3GPP Release 15, Sub-6GHz NR (NSA/SA) |
| 5G Max Downlink | Up to 4.67 Gbps (theoretical, 5G NR) |
| LTE Support | LTE-A Pro Cat-20, up to 2 Gbps downlink |
| SIM Slots | 2× Nano-SIM (dual-SIM for carrier redundancy and failover) |
| Wi-Fi Standard | IEEE 802.11ax (Wi-Fi 6), dual-band concurrent |
| 2.4 GHz Radio | 802.11b/g/n/ax, up to 574 Mbps |
| 5 GHz Radio | 802.11a/n/ac/ax, up to 2402 Mbps |
| Wi-Fi Features | OFDMA, MU-MIMO (2×2), BSS Coloring, TWT, WPA3 |
| Antennas | 4× internal high-gain antennas (2× per band) |
| Ethernet Ports | 5× Gigabit Ethernet (1× primary LAN/WAN, 1× secondary WAN/LAN, 3× LAN switch) |
| PoE Output | 1× PoE output port (802.3af/at passthrough on designated port) |
| CPU | IPQ-6010 quad-core ARM Cortex-A53, 864 MHz |
| RAM | 1 GB DDR3 |
| Storage | 128 MB NAND Flash |
| Operating System | RouterOS v7 (L4 license) |
| Routing Protocols | BGP, OSPF, RIP, MPLS, Static, Policy Routing |
| Firewall & Security | Stateful firewall, NAT, IPsec, OpenVPN, WireGuard, L2TP, SSTP |
| USB Port | 1× USB 2.0 Type-A |
| Power Input | 24V passive PoE or DC jack (included power adapter 24V/1.2A) |
| Power Consumption | Max 24 W (including connected 5G modem and PoE output) |
| Form Factor | Desktop / Wall-mountable, compact enclosure |
| Operating Temperature | −20°C to +60°C |
| Dimensions | 220 × 220 × 59 mm (approximate) |
Available from Omnixon Global. Submit an RFQ and our team will confirm configuration and availability for your order.
Technical Specifications
| Brand | MikroTik |
| Category | Wireless Access Points |
| SKU | MIKR-D53G5HACD2HNDTCRG502QEA |
| Part Number | D53G-5HacD2HnD-TC&RG502Q-EA |
| Condition | New |
| Model | Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) |
| 5G Modem | Quectel RG502Q-EA (Qualcomm SDX55) |
| 5G Standard | 3GPP Release 15, Sub-6GHz NR (NSA/SA) |
| 5G Max Downlink | Up to 4.67 Gbps (theoretical, 5G NR) |
| LTE Support | LTE-A Pro Cat-20, up to 2 Gbps downlink |
| SIM Slots | 2× Nano-SIM (dual-SIM for carrier redundancy and failover) |
| Wi-Fi Standard | IEEE 802.11ax (Wi-Fi 6), dual-band concurrent |
| 2.4 GHz Radio | 802.11b/g/n/ax, up to 574 Mbps |
| 5 GHz Radio | 802.11a/n/ac/ax, up to 2402 Mbps |
| Wi-Fi Features | OFDMA, MU-MIMO (2×2), BSS Coloring, TWT, WPA3 |
| Antennas | 4× internal high-gain antennas (2× per band) |
| Ethernet Ports | 5× Gigabit Ethernet (1× primary LAN/WAN, 1× secondary WAN/LAN, 3× LAN switch) |
| PoE Output | 1× PoE output port (802.3af/at passthrough on designated port) |
| CPU | IPQ-6010 quad-core ARM Cortex-A53, 864 MHz |
| RAM | 1 GB DDR3 |
| Storage | 128 MB NAND Flash |
| Operating System | RouterOS v7 (L4 license) |
| Routing Protocols | BGP, OSPF, RIP, MPLS, Static, Policy Routing |
| Firewall & Security | Stateful firewall, NAT, IPsec, OpenVPN, WireGuard, L2TP, SSTP |
| USB Port | 1× USB 2.0 Type-A |
| Power Input | 24V passive PoE or DC jack (included power adapter 24V/1.2A) |
| Power Consumption | Max 24 W (including connected 5G modem and PoE output) |
| Form Factor | Desktop / Wall-mountable, compact enclosure |
| Operating Temperature | −20°C to +60°C |
| Dimensions | 220 × 220 × 59 mm (approximate) |
Frequently Asked Questions about MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA)
What does the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) do?
The MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
What does the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) do?
The MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
What are the headline specs of the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA)?
Key specifications for the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA): new condition; manufacturer MikroTik; model Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA); 5g modem Quectel RG502Q-EA (Qualcomm SDX55); 5g standard 3GPP Release 15, Sub-6GHz NR (NSA/SA); 5g max downlink Up to 4.67 Gbps (theoretical, 5G NR); lte support LTE-A Pro Cat-20, up to 2 Gbps downlink. Manufacturer part number D53G-5HacD2HnD-TC&RG502Q-EA. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
What are the headline specs of the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA)?
Key specifications for the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA): new condition; manufacturer MikroTik; model Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA); 5g modem Quectel RG502Q-EA (Qualcomm SDX55); 5g standard 3GPP Release 15, Sub-6GHz NR (NSA/SA); 5g max downlink Up to 4.67 Gbps (theoretical, 5G NR); lte support LTE-A Pro Cat-20, up to 2 Gbps downlink. Manufacturer part number D53G-5HacD2HnD-TC&RG502Q-EA. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) compatible with my infrastructure?
The MikroTik Chateau 5G ax (D53G-5HacD2HnD-TC&RG502Q-EA) interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
