Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module
Brand: Cisco | Category: Network Switches
SKU: CSC-N5K-C5548UP-FA | Part #: N5K-C5548UP-FA | MPN: N5K-C5548UP-FA
Contact for Pricing — Request a Quote
About the Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module
The Cisco Nexus N5K-C5548UP-FA delivers 32 fixed 10GbE unified ports in a compact 1RU form factor, engineered for high-density datacenter deployments requiring unified fabric capabilities. This fixed-configuration chassis from the Cisco Nexus 5500 Platform series achieves 960 Gbps switching capacity and sustains 714.4 Mpps forwarding rate, making it ideal for environments where performance density and operational efficiency are paramount. The platform supports native FCoE (Fibre Channel Forwarder), FC over Ethernet, and NPIV, enabling consolidation of storage and Ethernet traffic across a single unified infrastructure while maintaining line-rate throughput across all 32 SFP+ ports.
Network engineers and datacenter architects implementing converged infrastructure solutions are primary adopters of the N5K-C5548UP-FA. This switch addresses the needs of organizations deploying Cisco Nexus 2000 Series Fabric Extenders via Fabric Extender Technology, requiring comprehensive Layer 2 switching features including IEEE 802.1Q VLANs, vPC (Virtual Port Channel), and advanced spanning tree protocols, alongside Layer 3 routing capabilities via optional L3 daughter card (IPv4 and IPv6 static, OSPF, EIGRP, BGP). Data center bridging features—PFC (IEEE 802.1Qbb), ETS (IEEE 802.1Qaz), and DCBX (IEEE 802.1AB)—ensure lossless fabric operation. The single expansion module slot provides flexibility for future enhancements, while dual hot-swappable redundant power supplies and hot-swappable fan modules with front-to-back airflow design minimize downtime and simplify maintenance in 24/7 environments. Management is delivered via dedicated out-of-band 10/100/1000 RJ-45 and RS-232 console, running Cisco NX-OS.
For procurement teams evaluating the Cisco Nexus 5500 Platform for immediate datacenter deployment, Omnixon Global offers direct access to the N5K-C5548UP-FA with full technical support and competitive regional pricing. Contact our team to submit a request for quotation and discuss your unified fabric requirements today.
Technical Specifications
| Brand | Cisco |
| Category | Network Switches |
| SKU | CSC-N5K-C5548UP-FA |
| Part Number | N5K-C5548UP-FA |
| Condition | New |
| Interface | 10GbE |
| Product Series | Cisco Nexus 5500 Platform |
| Form Factor | 1RU fixed-configuration chassis |
| Airflow Direction | Front-to-back (port-side to non-port-side) |
| Fixed Unified Ports | 32 x SFP+ Universal Ports (10GbE / FCoE / native FC) |
| Expansion Module Slots | 1 |
| Switching Capacity | 960 Gbps |
| Forwarding Rate | 714.4 Mpps |
| Layer 2 Features | IEEE 802.1Q VLANs, vPC (Virtual Port Channel), Spanning Tree (RSTP/MSTP), LACP |
| Layer 3 Features | IPv4 and IPv6 routing (static, OSPF, EIGRP, BGP) with L3 daughter card |
| Unified Fabric / FCoE | Native FCoE (Fibre Channel Forwarder), FC over Ethernet, NPIV support |
| Data Center Bridging | PFC (IEEE 802.1Qbb), ETS (IEEE 802.1Qaz), DCBX (IEEE 802.1AB) |
| Fabric Extender Support | Cisco Nexus 2000 Series FEX via Fabric Extender Technology |
| Management Interfaces | 1 x RJ-45 10/100/1000 out-of-band management, 1 x RS-232 console |
| Operating System | Cisco NX-OS |
| Power Supplies | 2 x hot-swappable redundant power supplies |
| Fans | Hot-swappable fan modules with front-to-back airflow |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Dimensions (H x W x D) | 1.72 in x 17.3 in x 20.3 in (1RU) |
| Compliance | CE, FCC Class A, UL, RoHS |
Frequently Asked Questions about Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module
What does the Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module do?
The Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
Is the Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module compatible with my infrastructure?
The Cisco Nexus 5000/5500/5600 N5K-C5548UP-FA Cisco Nexus datacenter switch / module interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
