ASUS ROG Hyperion GR701 EATX Enterprise Chassis
Brand: ASUS | Category: Accessories & Components
SKU: GR701 | Part #: GR701 | MPN: GR701
Contact for Pricing — Request a Quote
About the ASUS ROG Hyperion GR701 EATX Enterprise Chassis
The ASUS ROG Hyperion GR701 is a full-tower EATX enterprise chassis engineered for tool-less assembly and flexible internal configurations. Built from steel with tempered glass front and left side panels, the GR701 (part number GR701) delivers both durability and visibility for high-performance workstation and server builds. This chassis accommodates motherboards up to EATX form factor (305 x 277 mm), while also supporting CEB, ATX, Micro-ATX, and Mini-ITX standards, making it a versatile platform for diverse enterprise deployments.
Storage architects and IT procurement teams will appreciate the GR701's expansive drive capacity and thermal flexibility. The chassis supports up to 8 x 2.5-inch drive bays plus 2 x 3.5-inch convertible bays, enabling substantial storage configurations for data-intensive applications. Cooling is handled by 4 pre-installed 140 mm ARGB fans, with support for up to 10 total fans and radiator mounting options including 420 mm front and top placement. The system accommodates CPU coolers up to 190 mm in height and GPUs extending to 600 mm in length, with 8 PCIe expansion slots and support for vertical GPU mounting via riser bracket. Front I/O connectivity includes 1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.2 Gen 1 Type-A ports, plus audio connections. ASUS has designed the power supply compartment with bottom-mount ATX form factor placement in a dual-chamber layout, optimizing airflow separation between PSU and components. At approximately 627 x 245 x 598 mm (H x W x D), the GR701 provides ample internal real estate for enterprise-grade configurations. For detailed specifications or custom integration requirements, contact Omnixon Global via RFQ.
Key Specifications
- Manufacturer: ASUS
- Part Number: GR701
- Form Factor: Full Tower
- Supported Motherboards: EATX (305 x 277 mm), CEB, ATX, Micro-ATX, Mini-ITX
- Maximum GPU Length: 600 mm
- Drive Bays: Up to 8 x 2.5-inch and 2 x 3.5-inch (convertible)
- Pre-installed Fans: 4 x 140 mm ARGB
- Front I/O Ports: 1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.2 Gen 1 Type-A, Audio
Technical Specifications
| Brand | ASUS |
| Category | Accessories & Components |
| SKU | GR701 |
| Part Number | GR701 |
| Condition | New |
| Manufacturer Part Number | GR701 |
| Product Line | ROG Hyperion |
| Form Factor | Full Tower |
| Supported Motherboard Form Factors | EATX (305 x 277 mm), CEB, ATX, Micro-ATX, Mini-ITX |
| Case Material | Steel, Tempered Glass |
| Maximum CPU Cooler Height | 190 mm |
| Maximum GPU Length | 600 mm |
| Maximum Radiator Support (Front) | 420 mm |
| Maximum Radiator Support (Top) | 420 mm |
| Maximum Radiator Support (Rear) | 120 mm |
| Pre-installed Fans | 4 x 140 mm ARGB |
| Maximum Fan Support | 10 fans |
| Drive Bays (2.5-inch) | Up to 8 x 2.5-inch |
| Drive Bays (3.5-inch) | 2 x 3.5-inch (convertible) |
| Front I/O Ports | 1 x USB 3.2 Gen 2x2 Type-C, 2 x USB 3.2 Gen 1 Type-A, Audio In/Out |
| PCIe Expansion Slots | 8 slots (supports vertical GPU mount via riser bracket) |
| Power Supply Form Factor | ATX (bottom-mount, dual-chamber) |
| Dimensions | Approximately 627 x 245 x 598 mm (H x W x D) |
| Tempered Glass Panels | Front and left side panels |
| Colour | Black |
Frequently Asked Questions about ASUS ROG Hyperion GR701 EATX Enterprise Chassis
What is the lead time on the ASUS ROG Hyperion GR701 EATX Enterprise Chassis?
Lead time depends on stock position. Submit the RFQ form on this page with your quantity and target date — our pre-sales team responds with a vendor-confirmed quote.
What support applies?
Full manufacturer support — sourced exclusively through distribution so serial-number registration and support claims process cleanly under your company name. Extended support and on-site support contracts available at quote time.
How do I get a formal quote?
Use the RFQ form on this page with quantity and destination country. Our pre-sales team responds with a vendor-confirmed quote, availability, and any matching support or commissioning options.
