Brand: APC | Category: Rack PDUs
SKU: AP8832 | Part #: AP8832 | MPN: AP8832
Contact for Pricing — Request a Quote
The APC by Schneider Electric Rack PDU 2G Metered (part number AP8832) is a 1U rack-mount power distribution unit. It accepts a 208V, 30A input through a NEMA L21-30P inlet and supports a maximum power capacity of 6.24 kW. Sixteen outlets are provided: twelve C13 and four C19.
The unit offers true RMS metering with outlet-level power monitoring. Management is handled through an embedded HTTP/HTTPS web server and SNMP v1/v2c/v3, so power data can be viewed remotely or brought into network management tools. It measures 1.73 x 17.3 x 4.3 inches and is rated for operating temperatures from 0 to 55°C.
This PDU is suited to server racks and network cabinets in data centres and equipment rooms, where it distributes power to installed hardware and gives visibility of power consumption for capacity planning.
Send the part number through our RFQ form and our team will reply within 48 hours.
| Brand | APC |
| Category | Rack PDUs |
| SKU | AP8832 |
| Part Number | AP8832 |
| Condition | New |
| Form Factor | 1U Rack |
| Manufacturer Part Number | AP8832 |
| Port Count | 16 outlets (12x C13, 4x C19) |
| Input Voltage | 208V |
| Input Current | 30A |
| Maximum Power Capacity | 6.24 kW |
| Inlet Type | NEMA L21-30P |
| Metering Capability | True RMS metering with outlet-level power monitoring |
| Management Interface | Embedded HTTP/HTTPS web server, SNMP v1/v2c/v3 |
| Dimensions | 1.73 x 17.3 x 4.3 inches (1U) |
| Operating Temperature | 0–55°C |
The APC by Schneider Electric Rack PDU 2G, Metered, 1U, 30A, 208V, (12) C13 & (4) C19 - AP8832 delivers conditioned, backed-up power for server rooms and data-center racks. Use cases include short-term ride-through during grid sag/spike events, graceful shutdown of critical compute, and runtime extension via external battery packs.
Key specifications for the APC by Schneider Electric Rack PDU 2G, Metered, 1U, 30A, 208V, (12) C13 & (4) C19 - AP8832: new condition; form factor 1U Rack; manufacturer part number AP8832; port count 16 outlets (12x C13, 4x C19); input voltage 208V; input current 30A; maximum power capacity 6.24 kW. Manufacturer part number AP8832. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
