WD Purple 10TB Surveillance Hard Drive
Brand: Western Digital | Category: Enterprise HDDs
SKU: 0F48514 | Part #: 0F48514 | MPN: WD101PURP
Contact for Pricing — Request a Quote
About the WD Purple 10TB Surveillance Hard Drive
The WD Purple 10TB Surveillance Hard Drive from Western Digital is enterprise-grade Enterprise HDDs hardware built for data centers. It features 10TB capacity, 3.5" form factor, SATA 6Gb/s interface, 5400 RPM speed. The WD Purple 10TB Surveillance Hard Drive (0F48514) is purpose-built for always-on video recording environments, utilizing Conventional Magnetic Recording (CMR) technology to deliver consistent, sequential write performance across continuous 24/7 operation cycles. Engineered specifically for digital video recorder and network video recorder systems, the drive supports simultaneous recording from up to 64 cameras, making it a reliable foundation for mid-to-large-scale surveil Available in brand new condition. Western Digital enterprise hdds products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Western Digital |
| Category | Enterprise HDDs |
| SKU | 0F48514 |
| Part Number | 0F48514 |
| MPN | WD101PURP |
| Condition | New |
| Capacity | 10TB |
| Form Factor | 3.5" |
| Interface | SATA 6Gb/s |
| Speed | 5400 RPM |
| Manufacturer Part Number | 0F48514 |
| Model Series | WD Purple |
| Formatted Capacity | 10TB |
| Form Factor | 3.5-inch |
| Interface | SATA 6Gb/s |
| Recording Technology | CMR (Conventional Magnetic Recording) |
| Spindle Speed | 5400 RPM |
| Cache (Buffer) | 256MB |
| Workload Rate (Annualized) | 180TB/yr |
| Maximum Supported Camera Streams | Up to 64 |
| Supported Operation | 24/7 continuous |
| Operating Temperature | 0°C to 65°C |
| Power Requirements (Read/Write) | 5.3W typical |
| Power Requirements (Standby/Idle) | 0.4W |
| Mean Time Between Failures (MTBF) | 1,000,000 hours |
| Load/Unload Cycles | 300,000 |
| Rotational Vibration Compensation | Yes (RV sensors supported in compatible enclosures) |
| AllFrame Technology | Yes |
| Compatible Systems | DVR, NVR |
| Dimensions (L x W x H) | 147mm x 101.6mm x 26.1mm |
| Weight | 540g |
Frequently Asked Questions about WD Purple 10TB Surveillance Hard Drive
What does the WD Purple 10TB Surveillance Hard Drive do?
At 10TB, the WD Purple 10TB Surveillance Hard Drive suits enterprise data-center storage tiers — all-flash arrays, hyperconverged storage pools (vSAN, Ceph), database backends, and high-throughput backup repositories. The SATA 6Gb/s interface is supported by major server platforms.
What are the headline specs of the WD Purple 10TB Surveillance Hard Drive?
Key specifications for the WD Purple 10TB Surveillance Hard Drive: capacity 10TB; form factor 3.5"; interface SATA 6Gb/s; new condition; product name WD Purple 10TB Surveillance Hard Drive; brand Western Digital; category HDD; capacity 10TB; form factor 3.5"; interface SATA 6Gb/s. Manufacturer part number 0F48514. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
Is the WD Purple 10TB Surveillance Hard Drive compatible with my infrastructure?
The WD Purple 10TB Surveillance Hard Drive uses a SATA 6Gb/s interface in a 3.5" form factor. It's compatible with server platforms that expose this interface — typical deployments include Dell PowerEdge, HPE ProLiant, Lenovo ThinkSystem, and Supermicro SuperServer chassis. For specific vendor part-number compatibility, our team validates against the manufacturer support matrix.
