Vertiv Liebert PSI5 Line-Interactive UPS 3kVA
Brand: Vertiv | Category: UPS & Power Protection
SKU: VERT-PSI53000RT120 | Part #: PSI5-3000RT120 | MPN: PSI5-3000RT120
Contact for Pricing — Request a Quote
About the Vertiv Liebert PSI5 Line-Interactive UPS 3kVA
The Vertiv Liebert PSI5 Line-Interactive UPS 3kVA from Vertiv is enterprise-grade UPS & Power Protection hardware built for data centers. Compact 3kVA line-interactive rack/tower UPS with intelligent LCD management and hot-swap battery capability for small server and network closet environments. Available in brand new condition. Available from Omnixon Global — contact our team to request a quote.
Technical Specifications
| Brand | Vertiv |
| Category | UPS & Power Protection |
| SKU | VERT-PSI53000RT120 |
| Part Number | PSI5-3000RT120 |
| Condition | New |
| Product Line | Liebert PSI5 |
| Topology | Line-Interactive with Automatic Voltage Regulation (AVR) |
| Output Power Capacity | 3000 VA / 2700 W |
| Input Voltage Range | 82 – 144 V AC (single-phase, without switching to battery) |
| Nominal Input Voltage | 120 V AC |
| Input Frequency Range | 40 – 70 Hz (auto-sensing) |
| Output Voltage | 120 V AC ± 5% |
| Output Frequency | 60 Hz ± 0.1 Hz (on battery) |
| Transfer Time | < 10 ms (line to battery) |
| Waveform (On Battery) | Pure Sine Wave |
| Battery Type | Maintenance-Free Sealed Lead-Acid (VRLA), Hot-Swappable |
| Typical Backup Runtime at Full Load | Approximately 4 minutes at 2700 W; runtime extendable via external battery cabinets |
| Typical Backup Runtime at Half Load | Approximately 11 minutes at 1350 W |
| Outlets | 8 × NEMA 5-15/20R (configurable in 2 outlet groups for load shedding) |
| Inlet Connector | NEMA L5-30P hardwire input with 6 ft. power cord |
| Communication Interfaces | USB (Type-B), RS-232 Serial, Dry Contact Port |
| Network Management | Optional Liebert IS-UNITY-DP or compatible network management card (accessory slot) |
| Display | Color LCD — load %, battery %, input/output voltage, runtime, active alarms |
| Form Factor | Convertible 2U Rack / Tower |
| Dimensions (Rack, H × W × D) | 3.4 in × 17.0 in × 24.0 in (86 mm × 432 mm × 610 mm) |
| Weight | Approximately 75 lbs (34 kg) with internal batteries |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Operating Humidity | 0% to 95% non-condensing |
| Noise Level | < 50 dBA at 1 meter |
| Certifications | UL 1778, FCC Part 15 Class A, RoHS compliant |
| Software Compatibility | Vertiv Liebert MultiLink, Vertiv Liebert Nform, compatible with third-party SNMP-based DCIM platforms |
