Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m
Brand: Mellanox | Category: Transceivers & Cables
SKU: MEL-MFS1S00-H090V | Part #: MFS1S00-H090V | MPN: MFS1S00-H090V
Contact for Pricing — Request a Quote
About the Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m
The Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m from Mellanox is enterprise-grade Transceivers & Cables hardware built for data centers. It features QSFP56 form factor, InfiniBand interface. The Mellanox MFS1S00-H090V is a QSFP56 HDR Active Optical Cable (AOC) designed to deliver 200Gb/s aggregate bandwidth across a 90-meter reach, making it one of the longest-range AOC solutions available for HDR InfiniBand and high-speed Ethernet fabric deployments. The cable integrates electrical-to-optical conversion circuitry within the QSFP56 connectors at each end, eliminating the need for separate transceivers and simplifying cable management in large-scale data center an Available in brand new condition. Mellanox transceivers & cables products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Mellanox |
| Category | Transceivers & Cables |
| SKU | MEL-MFS1S00-H090V |
| Part Number | MFS1S00-H090V |
| Condition | New |
| Form Factor | QSFP56 |
| Interface | InfiniBand |
| Product Family | LinkX |
| Cable Type | Active Optical Cable (AOC) |
| Connector Type | QSFP56 |
| Protocol | HDR InfiniBand / 200GbE |
| Aggregate Data Rate | 200Gb/s |
| Lane Configuration | 2 x 100Gb/s |
| Cable Length | 90 m |
| Transmission Medium | Multi-mode optical fiber |
| Operating Temperature | 0°C to 70°C |
| Power Consumption | ≤ 4.5 W per end (connector) |
| EMI Immunity | Immune to electromagnetic interference (optical transmission) |
| Form Factor | QSFP56 |
| Compliance | InfiniBand Trade Association (IBTA) HDR specification |
| Host Interface | QSFP56 electrical interface |
| Hot-Pluggable | Yes |
| Jacket | LSZH (Low Smoke Zero Halogen) |
| RoHS Compliance | RoHS compliant |
Frequently Asked Questions about Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m
What does the Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m do?
The Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m is enterprise IT hardware deployed in production data centers, server rooms, and edge sites across the GCC and EMEA region.
What are the headline specs of the Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m?
Key specifications for the Mellanox MFS1S00-H090V LinkX QSFP56 HDR Active Optical Cable, 90m: form factor QSFP56; interface InfiniBand; new condition; cable type Active optical cable (AOC); connector a QSFP56; connector b QSFP56; length 90m; use case HDR InfiniBand and high-speed switch/server interconnects. Manufacturer part number MFS1S00-H090V. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
