Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m
Brand: Mellanox | Category: Transceivers & Cables
SKU: MEL-MFS1S00-H005V | Part #: MFS1S00-H005V | MPN: MFS1S00-H005V
Contact for Pricing — Request a Quote
About the Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m
The Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m from Mellanox is enterprise-grade Transceivers & Cables hardware built for data centers. It features QSFP56 form factor, InfiniBand interface. The Mellanox MFS1S00-H005V is a QSFP56 HDR Active Optical Cable (AOC) engineered for 200Gb/s InfiniBand HDR and high-density data center interconnect environments. Operating as a single-port 200Gb/s assembly, it integrates active optical transceiver electronics directly within the QSFP56 connectors at each end of a 5-meter fiber assembly, eliminating the need for separate optical modules or patch panels. The cable fully conforms to the QSFP56 form factor specification and is Available in brand new condition. Mellanox transceivers & cables products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Mellanox |
| Category | Transceivers & Cables |
| SKU | MEL-MFS1S00-H005V |
| Part Number | MFS1S00-H005V |
| Condition | New |
| Form Factor | QSFP56 |
| Interface | InfiniBand |
| Manufacturer Part Number | MFS1S00-H005V |
| Cable Type | Active Optical Cable (AOC) |
| Form Factor | QSFP56 |
| Protocol | InfiniBand HDR |
| Data Rate | 200Gb/s aggregate |
| Per-Lane Data Rate | 50Gb/s (4 lanes) |
| Lane Count | 4 TX / 4 RX |
| Cable Length | 5 meters |
| Fiber Type | Multimode optical fiber |
| Connector Type | QSFP56 (both ends) |
| Hot-Pluggable | Yes |
| Digital Diagnostics Monitoring | Yes (DDM/DOM, SFF-8636 compliant) |
| Management Interface | I2C via SFF-8636 |
| Compatibility | Mellanox Quantum HDR InfiniBand switches and ConnectX-6 / ConnectX-6 Dx HDR HCAs |
| RoHS Compliance | Yes |
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to +85°C |
Frequently Asked Questions about Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m
What does the Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m do?
The Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m is enterprise IT hardware deployed in production data centers, server rooms, and edge sites across the GCC and EMEA region.
What are the headline specs of the Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m?
Key specifications for the Mellanox MFS1S00-H005V LinkX QSFP56 HDR Active Optical Cable, 5m: form factor QSFP56; interface InfiniBand; new condition; cable type Active optical cable (AOC); connector a QSFP56; connector b QSFP56; length 5m; use case HDR InfiniBand and high-speed switch/server interconnects. Manufacturer part number MFS1S00-H005V. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
