Huawei UPS5000-E-600K-FM Modular UPS
Brand: Huawei | Category: UPS & Power Protection
SKU: H-UPS5000-E-600K-FM | Part #: UPS5000-E-600K-FM | MPN: UPS5000-E-600K-FM
Contact for Pricing — Request a Quote
About the Huawei UPS5000-E-600K-FM Modular UPS
The Huawei UPS5000-E-600K-FM Modular UPS from Huawei is enterprise-grade UPS & Power Protection hardware built for data centers. It features 600 kVA capacity. The Huawei UPS5000-E-600K-FM is a high-capacity modular uninterruptible power supply engineered for large-scale enterprise and data center environments. Built on a hot-swap modular architecture, the system allows individual power modules to be inserted or removed without interrupting the load, enabling online capacity expansion and concurrent maintainability without scheduled downtime. The unit operates at a rated output capacity of 600 kVA / 600 kW, achieving a unity power f Available in brand new condition. Huawei ups & power protection products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Huawei |
| Category | UPS & Power Protection |
| SKU | H-UPS5000-E-600K-FM |
| Part Number | UPS5000-E-600K-FM |
| Condition | New |
| Capacity | 600 kVA |
| Manufacturer Part Number | UPS5000-E-600K-FM |
| Topology | Double-conversion online (VFI, Voltage and Frequency Independent) |
| Rated Output Capacity | 600 kVA / 600 kW |
| Output Power Factor | 1.0 |
| System Architecture | Hot-swap modular; online capacity expansion and concurrent maintainability |
| Double-Conversion Efficiency (Full Load) | Up to 96% |
| ECO Mode Efficiency | Up to 99% |
| Input Voltage (3-phase) | 380 / 400 / 415 V AC (3P+N+PE) |
| Input Frequency | 45–55 Hz (wide range) / 50 Hz nominal |
| Input THDi | < 3% (at full load, with active front-end rectifier) |
| Output Voltage | 380 / 400 / 415 V AC (3P+N+PE) |
| Output Frequency | 50 Hz ± 0.1 Hz (inverter mode) |
| Output Voltage THD | < 1% (linear load) / < 3% (non-linear load) |
| Transfer Time (Mains to Battery) | 0 ms (double-conversion, uninterrupted) |
| Parallel Redundancy Support | Yes; multiple frames can be paralleled for N+X redundancy |
| Battery Compatibility | External battery cabinet (VRLA or lithium-ion, configured per deployment) |
| Communication Interfaces | Dry contacts, RS485, Modbus, SNMP (via network management module) |
| Protection Class | IP20 |
| Cooling Method | Forced air cooling (intelligent variable-speed fans) |
Frequently Asked Questions about Huawei UPS5000-E-600K-FM Modular UPS
What does the Huawei UPS5000-E-600K-FM Modular UPS do?
The Huawei UPS5000-E-600K-FM Modular UPS delivers conditioned, backed-up power for server rooms and data-center racks. Use cases include short-term ride-through during grid sag/spike events, graceful shutdown of critical compute, and runtime extension via external battery packs.
What are the headline specs of the Huawei UPS5000-E-600K-FM Modular UPS?
Key specifications for the Huawei UPS5000-E-600K-FM Modular UPS: capacity 600 kVA; 3 years support; new condition; support 3 years standard (manufacturer). Manufacturer part number UPS5000-E-600K-FM. For the full datasheet with electrical, environmental, and compliance details, contact our pre-sales engineering team.
