HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A)
Brand: HPE | Category: Network Switches
SKU: ARUBA-CX6300M-48P-001 | Part #: JL662A | MPN: JL662A
Contact for Pricing — Request a Quote
About the HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A)
The HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) from HPE is enterprise-grade Network Switches hardware built for data centers. It features 1GbE interface, 1GbE speed. The HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) is a high-performance Layer 3 campus access switch built on the AOS-CX operating system, a modern, database-driven network OS engineered for automation, programmability, and simplified operations. The 6300M series is purpose-built for enterprise campus deployments requiring reliable Power over Ethernet delivery at scale, combining 48 downlink ports capable of IEEE 802.3at (PoE+) Class 4 power delivery with high-s Available in brand new condition. HPE network switches products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | HPE |
| Category | Network Switches |
| SKU | ARUBA-CX6300M-48P-001 |
| Part Number | JL662A |
| Condition | New |
| Interface | 1GbE |
| Speed | 1GbE |
| Product Line | CX 6300M |
| Manufacturer Part Number | JL662A |
| Switch Type | Layer 3 Managed |
| Operating System | AOS-CX |
| Total Ports | 56 |
| Downlink Ports | 48 x 1GbE RJ-45 PoE+ |
| Uplink Ports | 4 x SFP56 (supports 1GbE / 10GbE / 25GbE) |
| PoE Standard | IEEE 802.3at (PoE+) Class 4 |
| PoE Budget | 740W |
| Stacking / High Availability | VSX (Virtual Switching Extension) active-active |
| MC-LAG Support | Yes |
| Routing Protocols | Static routing, RIP, OSPF, BGP, PBR |
| Multicast Support | PIM-SM, PIM-SSM, IGMP v1/v2/v3 |
| IPv6 Support | Yes (dual-stack) |
| VLANs | Up to 4094 |
| ACL Support | Yes (IPv4 and IPv6) |
| QoS | Yes (8 queues per port, DSCP, 802.1p) |
| Management | REST API, CLI, SNMP v2c/v3, HPE Aruba Central (cloud), Aruba Fabric Composer |
| Programmability | On-box Python scripting, Network Analytics Engine (NAE) |
| Form Factor | 1U rack-mount |
| Power Supplies | Dual redundant hot-swap power supplies supported |
Frequently Asked Questions about HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A)
What does the HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) do?
The HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
Is the HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) compatible with my infrastructure?
The HPE Aruba CX 6300M 48-Port 1GbE PoE Class 4 Switch (JL662A) interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
