Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch
Brand: Cisco | Category: Network Switches
SKU: MERAKI-MS130-48P-001 | Part #: MS130-48P-HW | MPN: MS130-48P-HW
Contact for Pricing — Request a Quote
About the Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch
The Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch from Cisco is enterprise-grade Network Switches hardware built for data centers. It features 1GbE interface, 1GbE speed. The Cisco Meraki MS130-48P is a cloud-managed access layer switch delivering 48 ports of Gigabit Ethernet with PoE+ capability and a 740W PoE power budget, purpose-built for enterprise campus and branch deployments. The switch operates entirely under the Meraki cloud management platform, enabling zero-touch provisioning, centralized policy enforcement, and real-time network visibility through a single browser-based dashboard without the need for on-premises controllers or com Available in brand new condition. Cisco network switches products are trusted by enterprises and data centers worldwide. Available from Omnixon Global. Contact our sales team to request a quote.
Technical Specifications
| Brand | Cisco |
| Category | Network Switches |
| SKU | MERAKI-MS130-48P-001 |
| Part Number | MS130-48P-HW |
| Condition | New |
| Interface | 1GbE |
| Speed | 1GbE |
| Manufacturer Part Number | MS130-48P-HW |
| Product Line | Cisco Meraki MS130 |
| Total Access Ports | 48 x 10/100/1000BASE-T Gigabit Ethernet (RJ-45) |
| Uplink Ports | 4 x 10G SFP+ |
| PoE Standard | IEEE 802.3at PoE+ on all 48 access ports |
| Total PoE Power Budget | 740W |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.95 Mpps |
| MAC Address Table Size | 16,000 entries |
| Jumbo Frame Support | 9,216 bytes |
| Layer | Layer 2 |
| VLAN Support | 802.1Q, up to 1,024 VLANs |
| Spanning Tree | IEEE 802.1D STP, IEEE 802.1w RSTP |
| Link Aggregation | IEEE 802.3ad LACP |
| Management | Cisco Meraki cloud dashboard (cloud-managed); no on-premises controller required |
| Mounting | 1U rack-mountable |
| Form Factor | 1U fixed configuration |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Input Voltage | 100–240V AC, 50/60Hz |
| Dimensions (W x D x H) | 440 x 300 x 44.5 mm (17.3 x 11.8 x 1.75 in) |
Frequently Asked Questions about Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch
What does the Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch do?
The Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch is enterprise networking hardware for data-center, campus, and branch deployments. Common roles include core/distribution switching, server uplinks, top-of-rack fabric, and edge connectivity in mixed Cisco/Juniper/Arista environments.
Is the Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch compatible with my infrastructure?
The Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Switch interoperates with standard switching protocols (LACP, MLAG/VPC, 802.1Q, OSPF/BGP). For specific cross-vendor scenarios — Cisco-to-Arista MLAG peering, fabric integration with Cumulus/SONiC, or migration from legacy Catalyst — our network engineers map a compatibility plan as part of the RFQ.
